Elo Touch Solutions I-Series E707193 All-in-One PC/workstation Intel® Core™ i3 i3-1215UL 54.6 cm (21.5") 1920 x 1080 pixels Touchscreen 8 GB DDR5-SDRAM 128 GB SSD Wi-Fi 6 (802.11ax) Black

21.5" TFT LCD (LED) 1920 x 1080, Intel Core i3-1215UL, 8 GB RAM, 128 SSD, No OS, With Stand

Description

Completely redesigned I‑Series 3 with Intel.

Brilliant and beautiful, interactive platform.

- 10-touch TouchPro PCAP
- Fanless, IP54 rated design
- Full HD IPS Touchscreen
- Easy to clean edge-to-edge glass
- 50,000 MTBF

Modular design.
Endless versatility.
Available in sizes ranging from 15 to 24 inches, including with and without stand options, you can easily configure the I‑Series to fit the needs of your business - from signage and point-of-sale to self-service, automation controls and more.

Universal VESA Mount
Conveniently mount the I‑Series with the built‑in VESA mount.

Expand with Edge Connect
Seamlessly attach a variety of peripherals to the edge of the touchscreen.

Reliable, security and performance.
Built with the reliability-tested performance and security of Intel 12th Generation processors, integrated Trusted Platform Modules, Intel vPro™ and the Windows 10 operating system, the I‑Series 3 delivers the dependability businesses need.

Enhanced connectivity for all your accessories.
- USB-C full featured
- Gigabit LAN
- Powered RJ50 Serial
- 4x USB 3.0
- 4x Micro-USB Edge Connect
- WiFi & Bluetooth 5.2

Specifications

Display
HD type	Full HD
Panel type	LCD
Display diagonal	54.6 cm (21.5")
Display resolution	1920 x 1080 pixels
Touchscreen	Yes
Display brightness	250 cd/m²
Native aspect ratio	16:9
Processor
Processor cache type	Smart Cache
Processor frequency	1.2 GHz
Processor family	Intel® Core™ i3
Processor model	i3-1215UL
Processor cores	6
Processor cache	10 MB
Processor manufacturer	Intel
Processor base power	15 W
Maximum turbo power	28 W
Efficient-core Max Turbo Frequency	2.5 GHz
Performance-core Max Turbo Frequency	4.4 GHz
Performance cores	2
Efficient cores	4
Memory
Memory form factor	DIMM/SO-DIMM
Internal memory	8 GB
Memory layout (slots x size)	1 x 8 GB
Maximum internal memory	32 GB
Internal memory type	DDR5-SDRAM
Memory slots	2
Memory slots type	SO-DIMM
Memory clock speed	4800 MHz
Hard drive
Storage media	SSD
Total storage capacity	128 GB
Storage
Storage media	SSD
Total storage capacity	128 GB
Optical drive type	No
SSD capacity	128 GB
Number of SSDs installed	1
Total SSDs capacity	128 GB
Graphics
Discrete graphics card	No
On-board graphics card family	Intel® UHD Graphics
On-board graphics card	Yes
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics
On-board GPU manufacturer	Intel
Audio
Number of speakers	2
Built-in speaker(s)	Yes
RMS rated power	4 W
Camera
Built-in camera	No
Optical drive
Optical drive type	No
Network
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth	Yes
Bluetooth version	5.2
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 2.0 ports quantity	4
HDMI ports quantity	0
Headphone outputs	1
Ethernet LAN (RJ-45) ports	1
DC-in jack	Yes
On/off button	Yes
Technical details
Product type	All-in-One PC
Product colour	Black
Sustainability compliance	Yes
Compliance certificates	RoHS
Security
Trusted Platform Module (TPM)	Yes
HDD user password	Yes
Design
Product colour	Black
On/off button	Yes
Performance
Product type	All-in-One PC
Trusted Platform Module (TPM)	Yes
HDD user password	Yes
Trusted Platform Module (TPM) version	2.0
Software
Operating system installed	No
Power
AC adapter power	180 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output voltage	24 V
Multimedia
Built-in camera	No
Weight & dimensions
Package width	645 mm
Package depth	316 mm
Package height	503 mm
Package weight	12 kg
Width (with stand)	525.8 mm
Depth (with stand)	204.6 mm
Height (with stand)	368.7 mm
Weight (with stand)	10.1 kg
Packaging data
Package width	645 mm
Package depth	316 mm
Package height	503 mm
Package weight	12 kg
Operational conditions
Operating temperature (T-T)	0 - 35 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	5 - 95%
Certificates
Certification	Canada cUL, IC; United States UL, FCC; Germany TUV; Europe CE; Australia RCM; United Kingdom UKCA; International CB; Argentina S-Mark; Brazil; ANATEL; Japan VCCI, MIC; China CCC, SRRC; Mexico NOM; RoHS CoC
Compliance certificates	RoHS
Sustainability
Sustainability compliance	Yes
Other features
On-board graphics card	Yes
SSD capacity	128 GB
Processor manufacturer	Intel
Number of SSDs installed	1
