SonicWall TZ670 hardware firewall Desktop 5 Gbit/s

Promotional Trade-Up with 3 Years Advanced Protection Service Suite (APSS) and 1 Year Cloud Secure Edge (CSE): SIA Basic 20 Users + SPA Advanced 6 Users, 5 Gbps, 3 Gbps IPS, 2.5 Gbps Threat, 2.1 Gbps VPN, SPI 1.5M, 25K CPS, 8x1GbE, 2x 10G SFP+

Description

TZ SERIES NEXT-GENERATION FIREWALL (NGFW)

Protect your small business or branch location from intrusion, malware and ransomware with an easy-to-use, integrated security solution designed specifically for your needs. SonicWall TZ firewalls deliver enterprise-grade protection without the cost or complexity.

In an era of the ever-evolving security landscape, small- and medium-sized businesses (SMB) face large challenges when it comes to defending their networks, data and reputation. Keeping up with changes in technology can be as difficult as tracking the growing number of threats.

The SonicWall TZ series of firewalls is designed specifically for the needs of SMBs and branch locations, delivering enterprise-class security without the enterprise-grade complexity.

With Zero-Touch Deployment and simplified centralized management, installation and operation is easy. Detect sophisticated threats, including encrypted attacks, with advanced networking and security features, like the multi-engine Capture Advanced Threat Protection (ATP) cloud-based sandbox service with patent-pending Real-Time Deep Memory Inspection (RTDMI™). With optional features like PoE/PoE+ support and 802.11ac Wi-Fi, create a unified security solution for wired and wireless networks.

Simply plug in and enjoy the advanced protection of the cost-effective SonicWall TZ series firewall without worrying about complex management — or the next threat.

Specifications

Data transmission
IPS/IDS throughput	3000 Mbit/s
Maximum firewall connections per second	25000
Maximum firewall connections	1500000
SSL inspection throughput	800 Mbit/s
IPSec VPN throughput	2.1 Gbit/s
Maximum connections (DPI)	500000
Maximum connections (SPI)	1500000
Threat protection throughput	2500 Mbit/s
Firewall throughput	5 Gbit/s
VPN throughput	2.1 Gbit/s
Firewall throughput	5000 Mbit/s
Performance
Heat dissipation	55.1 BTU/h
Certification	FCC Class B, FCC, ICES Class B, CE (EMC, LVD, RoHS), C-Tick, VCCI Class B, UL/cUL, TUV/GS, CB, Mexico DGN notice by UL, WEEE, REACH, BSMI, KCC/MSIP, ANATEL
Network
Point-to-point protocol over Ethernet (PPPoE)	Yes
Wi-Fi	No
VPN tunnels quantity	250
Local user database	250
Quality of Service (QoS) support	Yes
Number of VLANs	256
DHCP server	Yes
Number of LAN Access Points (max)	32
Protocols
Routing protocols	BGP, OSPF, RIP-1, RIP-2
Management features
LED indicators	Yes
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
SFP+ module slots quantity	2
Gigabit Ethernet (copper) ports quantity	8
Connectivity technology	Wired
WAN connection	Mobile network (USB), Ethernet (RJ-45), SFP+
Ethernet LAN (RJ-45) ports	8
Ethernet LAN data rates	1000,10000,2500,5000 Mbit/s
Console port	USB
Number of console ports	1
Storage
Total storage capacity	32 GB
Design
Form factor	Desktop
Built-in display	No
Power
AC input voltage	100-240 V
Redundant power supply (RPS) support	Yes
Power supply	60 W
Power consumption (max)	13.1 W
Certificates
Certification	FCC Class B, FCC, ICES Class B, CE (EMC, LVD, RoHS), C-Tick, VCCI Class B, UL/cUL, TUV/GS, CB, Mexico DGN notice by UL, WEEE, REACH, BSMI, KCC/MSIP, ANATEL
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95%
Storage relative humidity (H-H)	5 - 95%
Weight & dimensions
Weight	970 g
Width	225 mm
Depth	150 mm
Height	35 mm
Technical details
Form factor	Desktop
Heat dissipation	55.1 BTU/h
Harmonized System (HS) code	85176990
Display
Built-in display	No
Hard drive
Total storage capacity	32 GB
Features
SSL inspection throughput	800 Mbit/s
Other features
Firewall throughput	5000 Mbit/s
Logistics data
Harmonized System (HS) code	85176990
