Panasonic Toughbook FZ-40FZ00DBE laptop Intel Core Ultra 5 135H 35.6 cm (14") Touchscreen Full HD 16 GB DDR5-SDRAM 512 GB SSD Wi-Fi 7 (802.11be) Windows 11 Pro Black

Toughbook 40 mk2, 14" LCD Full-HD (1920x1080) Touch Screen, Intel Core Ultra5 135H, Intel Arc Graphics, 16GB DDR5 RAM, 512GB NVMe OPAL SSD, Intel Wi-Fi 7 BE200, Bluetooth 5.3, 4G, Windows 11 Pro

Description

AI capabilities underpinned by enhanced graphics performance
One of the first rugged notebooks using Windows 11 Pro to offer AI edge processing capabilities, the new 14-inch TOUGHBOOK 40 utilises the Intel® Core™ Ultra 5 processor 135H (with Intel vPro® Technology).

For those requiring unmatched performance for the most demanding applications, the optional new Intel® Core™ Ultra7 processor 165H (with Intel vPro® Technology) delivers an additional boost in computing power.

Both processors feature a dedicated AI chipset that enables data to be collected, stored, and analysed using artificial intelligence, without uploading and downloading data through a connection to the cloud – and without affecting the device’s overall performance and processing power.

Future-proofed connectivity
The TOUGHBOOK 40mk2 is better connected than ever before as one of the first rugged notebooks to include the latest Intel® Wi-Fi 7 BE200 specification. The increased connectivity speeds (up to 5.8 Gbps and greater than 2x compared to Wi-Fi 6E) and ultra-low latency, enable field workers to take advantage of reliable, super-fast transfers of data when back in the office or field base.

For truly remote workers, the new TOUGHBOOK 40 features optional 4G and 5G connectivity with eSIM support, providing reliable connectivity on the move.

Market-leading ruggedness or modularity
The TOUGHBOOK 40mk2 features the same market-leading ruggedness and modularity, providing the modern mobile worker with a balanced solution, regardless of the task, application or environment.

The latest TOUGHBOOK 40 is IP66**-rated for water and dust ingress and can comfortably operate in temperatures between -29°C and +63°C**, ensuring that productivity isn’t affected. In addition to a replaceable battery, storage and RAM, the 40mk2 also features four additional expansion areas, providing maximum flexibility.

The increased graphics performance and AI-enabled edge processing doesn’t compromise the TOUGHBOOK 40mk2’s battery performance. The 40mk2 delivers up to 12 hours (MobileMark 25) from a single battery, giving today’s modern worker peace of mind when using power-hungry applications.

Designed for discretion
On the road or in the field, the TOUGHBOOK 40 notebook is geared up for vehicle diagnostics and maintenance as well as defence training. It also has a new all-black exterior, and a one touch Concealed Mode function, making it the perfect partner for operations that require some stealth.

Reliable tool for service technicians
For service technicians, it's the ideal tool for mobile working outdoors: it withstands extreme temperatures, has a 14" outdoor viewable screen, and can even be used in the rain while wearing gloves. Modularly and adaptable, its adept at multiple tasks: from solar panel installation and maintenance of utilities infrastructure to maritime repairs in salt spray conditions.

No more device failures, downtime or interrupted work
Engineered from the ground up to be used on-the-go and in harsh environments, this device is tested to military standard (MILSTD810H) and is the first TOUGHBOOK notebook that contains a complete IP66 rating. It’s also built to withstand drops of up to 180cm as well as knocks, vibrations and extreme temperatures for ultimate reliability in any environment.

Specifications

Design
Product type	Laptop
Form factor	Clamshell
Product colour	Black
Rugged design	Yes
Stylus pen support	Yes
Display
HD type	Full HD
Panel type	IPS
Display brightness	1200 cd/m²
Touchscreen	Yes
Display resolution	1920 x 1080 pixels
Display diagonal	35.6 cm (14")
Anti-reflective coating	Yes
Processor
Processor generation	Intel® Core™ Ultra (Series 1)
Processor cache type	Smart Cache
Processor cache	18 MB
Processor model	135H
Processor cores	14
Processor threads	18
Processor manufacturer	Intel
Processor family	Intel Core Ultra 5
Processor base power	28 W
Maximum turbo power	115 W
Efficient-core base frequency	1.2 GHz
Performance-core base frequency	1.7 GHz
Efficient-core Max Turbo Frequency	3.6 GHz
Performance-core Max Turbo Frequency	4.6 GHz
Performance cores	4
Efficient cores	8
Low Power Efficient-core Base Frequency	700 MHz
Low Power Efficient-core Max Turbo Frequency	2.5 GHz
Low Power Efficient-cores	2
Neural processor unit (NPU)
Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Yes
Windows Studio effects support	Yes
AI software frameworks supported by NPU	DirectML, ONNX RT, OpenVINO, Windows ML
Memory
Memory form factor	SO-DIMM
Internal memory	16 GB
Internal memory type	DDR5-SDRAM
Memory clock speed	5600 MHz
Memory slots	2x SO-DIMM
Maximum internal memory	64 GB
Storage
Storage media	SSD
Optical drive type	No
Number of SSDs installed	1
SSD capacity	512 GB
Card reader integrated	Yes
Compatible memory cards	SDXC
Total storage capacity	512 GB
NVMe	Yes
Graphics
Discrete graphics card	No
On-board graphics card	Yes
On-board graphics card model	Intel Arc Graphics
Discrete graphics card model	Not available
On-board GPU manufacturer	Intel
Audio
Audio system	MaxxAudio
Camera
Front camera	Yes
Front camera resolution (numeric)	5 MP
Privacy camera	Yes
Privacy type	Privacy shutter
Windows Hello	Yes
Optical drive
Optical drive type	No
Network
Mobile network connection	Yes
Mobile network generation	4G
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
WLAN controller model	Intel Wi-Fi 7 BE200
Wi-Fi standards	Wi-Fi 7 (802.11be)
Ethernet LAN	Yes
Bluetooth	Yes
Bluetooth version	5.3
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
HDMI ports quantity	1
Combo headphone/mic port	Yes
Thunderbolt 4 ports quantity	1
DC-in jack	Yes
Keyboard
Pointing device	Touchpad
Keyboard layout	QWERTY
Numeric keypad	No
Keyboard language	UK English
Software
Operating system architecture	64-bit
Operating system installed	Windows 11 Pro
Technical details
Form factor	Clamshell
Product colour	Black
Battery
Battery technology	Lithium-Ion (Li-Ion)
Battery life (max)	12 h
Battery capacity	6300 mAh
Battery voltage	10.8 V
Power
AC adapter frequency	50/60 Hz
AC adapter input voltage	100-240 V
AC adapter output current	7.05 A
AC adapter output voltage	15.6 V
USB Type-C charging port	No
DC-in jack	Yes
Security
Password protection	Yes
Trusted Platform Module (TPM)	Yes
Cable lock slot	Yes
Windows Hello	Yes
Trusted Platform Module (TPM) version	2.0
Operational conditions
Operating temperature (T-T)	-29 - 63 °C
Drop proof	180 cm
Weight & dimensions
Width	354 mm
Depth	301 mm
Height	54.4 mm
Weight	3.35 kg
Packaging data
AC adapter included	Yes
Packaging content
AC adapter included	Yes
Other features
WLAN controller model	Intel Wi-Fi 7 BE200
On-board graphics card	Yes
Audio system	MaxxAudio
AC adapter included	Yes
