D-Link 24-Port 2.5G Multi-Gigabit Unmanaged Switch

24 x 10M/100M/1G/2.5G, 120 Gbps, 89.28 Mbps, 440 x 250 x 44 mm, 3.421 kg

Key Features

• 24-port 2.5GE connectivity for high performance networking
• Plug and Play simplicity for easy installation
• Smart Fan design for enhanced cooling and low noise operation
• Durable rackmount metal housing enhances product durability
• IGMP snooping for optimized bandwidth utilization
• Auto MDI/MDI-X crossover on all ports simplifies setup
• IEEE 802.3x flow control prevents packet loss
• Quality of Service (QoS) ensures uninterrupted connectivity
• IEEE 802.3az reduces power consumption and operating cost

Description

Plug & Play
No complex configurations required for fast and easy network connectivity

2.5G Ports
Multi-Gigabit ports for high data rate transmission

Multicast Optimization
IGMP snooping feature prevents network flooding

Rugged Design
Compact metal casing improves device durability

Low-Noise Operation
Smart fan enhances device cooling efficiently

Optimized Performance
QoS prioritizes traffic, enhancing user experience

2.5G Ports for Faster Data Rates
New generation Wi-Fi delivers ultra-fast speeds with low latency and standard Gigabit Ethernet can become a bottleneck. 2.5G Ethernet offers 2.5x the bandwidth without new cabling, enabling significantly faster data rates for Wi-Fi APs, smoother 4K/8K streaming, HD surveillance, AR/VR gaming, NAS, and many more applications in data-intensive environments.

Smarter Multicast, Smoother Performance
The DMS-1024 enables IGMP Snooping to enhance network efficiency by intelligently managing multicast traffic, ensuring data reaches only the devices that need it. This reduces bandwidth congestion, improves video streaming and VoIP performance, and optimizes IPTV, surveillance, and enterprise networks.

Prioritize Traffic for Optimized Performance
With the DMS-1024, you can effortlessly manage your network traffic with the 802.1p Quality of Service (QoS) feature. The switch automatically organizes and prioritizes time-sensitive and critical data for efficient delivery, enabling buffer-free video streaming as well as jitter-free video and voice calls.

Eco-Friendly and Cost Saving
The DMS-1024 optimizes energy use and cuts operating costs with intelligent power management that reduces consumption during idle periods. The Smart Fan design enables variable speed and low-noise operation while minimizing expenses. Experience a cost-effective, eco-friendly solution that saves money and promotes sustainability.

Specifications

Management features
Traffic classification	Yes
Switch type	Unmanaged
Quality of Service (QoS) support	Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	2.5G Ethernet (100/1000/2500)
Power connector	DC-in jack
Network
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3p, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
Auto MDI/MDI-X	Yes
10G support	No
Data transmission
Jumbo frames	12288
MAC address table	32000 entries
Switching capacity	120 Gbit/s
Store-and-forward	Yes
Jumbo frames support	Yes
Forwarding rate	89.28 Mpps
Design
Product colour	Black
Stackable	Yes
LED indicators	Yes
Certification	LVD; CE Class A, FCC Class A
Performance
Mean time between failures (MTBF)	646913.55 h
Stackable	Yes
Power
Power consumption (max)	35.489 W
Power supply included	Yes
Input current	5.4 A
DC input voltage	12 V
Power source	DC
Power connector	DC-in jack
Power over Ethernet (PoE)
Power over Ethernet (PoE)	No
Operational conditions
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	0 - 95%
Operating temperature (T-T)	-5 - 50 °C
Operating relative humidity (H-H)	0 - 95%
Heat dissipation	62.29 BTU/h
Weight & dimensions
Width	440 mm
Depth	250 mm
Height	44 mm
Weight	3.42 kg
Packaging content
Quick start guide	Yes
Technical details
Product colour	Black
Stackable	Yes
Mean time between failures (MTBF)	646913.55 h
Certificates
Certification	LVD; CE Class A, FCC Class A
Indication
LED indicators	Yes
Packaging data
Quick start guide	Yes
Other features
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
