Alcatel-Lucent ALE-2 IP phone Grey LCD

2.8-inch, 132 x 64, LCD, IEEE 802.3af, 9 function keys, SIP, RJ-45, RJ-9

Description

The ALE DeskPhones Basic range offers high performance, entry-level wired SIP DeskPhones with rich communications functionality for Alcatel-Lucent Enterprise solutions.

Both the handset and speakerphone offer wideband audio, ensuring clear communications for improved focus and interaction during important conversations.

The Basic DeskPhones, ALE-2 and ALE-3, are configured with a 2.8-inch display that fits up to four (4) lines of text and supports up to 1000 contacts and call logs. The six-way conferencing1 , local directory and up to four (4) separate lines make it easy for all departments to communicate. These phones are compliant with the interoperable SIP standard and offer secure communications for remote workers using a SIP Session Border Controller.

Manage calls easily and quickly using the contextual menus and four-way navigation. Never miss calls with the 1000-entry call history. These Basic DeskPhones are fully compatible with Alcatel-Lucent OmniPCX® Enterprise, Alcatel-Lucent OXO Connect, Rainbow Hub2 and RingCentral MVP®

The Basic business phones supports the use of an external power supply and Power over Ethernet (PoE). Both phones are compatible with ALE Easy Deployment Server (EDS) and Easy Device Management (EDM), providing easy large-scale configuration and deployment.

Specifications

Features
Dual-Tone Multi-Frequency (DTMF) modes	In-band, SIP info
Integrated voicemail	Yes
Handset type	Wired handset
Mounting	Desk/Wall
Wall mountable	Yes
Volume control	Buttons
Handset	Yes
Product colour	Grey
Backlight colour	White
Technical details
Dual-Tone Multi-Frequency (DTMF) modes	In-band, SIP info
Integrated voicemail	Yes
Handset type	Wired handset
Mounting	Desk/Wall
Volume control	Buttons
Speakerphone	Yes
Handset	Yes
Backlight colour	White
Sustainability certificates	ENERGY STAR, ErP
Compliance certificates	China RoHS, Federal Communications Commission (FCC), REACH, RoHS, WEEE
Design
Product type	IP Phone
Handset type	Wired handset
Mounting	Desk/Wall
Wall mountable	Yes
Product colour	Grey
Performance
Dual-Tone Multi-Frequency (DTMF) modes	In-band, SIP info
Phone features
Call transfer	Yes
Call log entries	1000
Speed dialling	Yes
Redialing	Yes
Phonebook capacity	1000 entries
Full duplex	Yes
Do not disturb function	Yes
Conference call	Yes
Caller ID	No
Call waiting	Yes
Call hold	Yes
Call forwarding	Yes
Management features
Integrated voicemail	Yes
Volume control	Buttons
Display
Touchscreen	No
Display resolution	132 x 64 pixels
Display diagonal	7.11 cm (2.8")
Display	LCD
Backlight display	Yes
Backlight colour	White
Audio
Comfort noise generation (CNG)	Yes
Voice codecs	G.711, G.722, G.729ab, iLBC
Voice activity detection	Yes
Speakerphone	Yes
Microphone mute	Yes
Echo cancellation	Yes
Network
Networking standards	IEEE 802.3af
Wi-Fi	No
Quality of Service (QoS) support	Yes
Ethernet LAN	Yes
Bluetooth	No
Colour
Product colour	Grey
Microphone
Microphone mute	Yes
Ergonomics
Wall mountable	Yes
Ports & interfaces
RJ-9 ports quantity	2
Ethernet LAN (RJ-45) ports	1
DC-in jack	Yes
Certificates
Sustainability certificates	ENERGY STAR, ErP
Power
Power over Ethernet (PoE)	Yes
Power consumption (Power over Ethernet (PoE))	2 W
Operational conditions
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	5 - 95%
Weight & dimensions
Width	191 mm
Depth	47 mm
Height	214 mm
Weight	795 g
Packaging content
Number of handles included	1 pc(s)
Manual	Yes
Handset	Yes
Stand included	Yes
