AudioCodes | SKU:
MP124/16S/AC/SIP
Sold out
15% off
AudioCodes MediaPack 124 gateway/controller
€881.72
€1,038.25
Unit price
/
Unavailable
Shipping calculated at checkout.
AudioCodes MediaPack 124 gateway/controller is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Delivery and Shipping
Delivery and Shipping
Products shipped within 2 working days from date of order.
Costs
0-24.99kg €14.50
25kg – 50kg €35.00
50kg and Up €60.00
No Customs Charges
No Customs Charges
Deliveries from Ireland & EU meaning no unwanted customs charges. No hidden charges.
MediaPack 124 Analog VoIP Gateway, 16FXS analog lines, single 10/100BaseT, AC power supply, life line support, G.711/723.1/726/727/729AB, SIP
- Service providers can use MediaPack gateways to connect Multi-Tenant Units (MTUs), IP Centrex subscribers, payphones, and rural users over wireless and satellite links
- Enterprises can use MediaPack gateways to connect their legacy PBX systems over an IP infrastructure. In addition, in IP Centrex and central IP-PBX applications, MediaPack enhances remote location availability and provides Stand Alone Survivability (SAS) when there is no IP connection between branch locations and a central SIP server, SIP proxy or central IP-PBX
The MediaPack 1xx gateways are fully interoperable with leading softswitches, SIP servers and H.323 systems.
Features
- Support for 2 to 24 analog ports
- T.38 fax compliant
- Rich subscriber feature set: 3-way conference with local mixing, call pickup, hunt groups, call forwarding, call hold and call transfer
- Echo cancellation, jitter buffer, voice activity detection (VAD) and comfort noise generation (CNG)
- Complies with MGCP, H.323v4 and SIP control protocols
Benefits
- Leverage investment in existing analog telephone, modem, and fax systems – easing VoIP migration
- Lifeline for fallback to PSTN for E911 (Emergency number PSTN breakthrough) or upon network/power failure (FXO and/or FXS configurations)
- Standalone Survivability (SAS) keeps your business running in the event of a network failure
Description
AudioCodes’ MediaPack 1xx series of Analog VoIP Gateways are cost-effective, stand-alone VoIP gateways that provide superior voice technology for connecting legacy telephones, fax machines and PBX systems with IP telephony networks and IP-based PBX systems. The MediaPack 1xx series gateways support a wide variety of service provider and enterprise applications:- Service providers can use MediaPack gateways to connect Multi-Tenant Units (MTUs), IP Centrex subscribers, payphones, and rural users over wireless and satellite links
- Enterprises can use MediaPack gateways to connect their legacy PBX systems over an IP infrastructure. In addition, in IP Centrex and central IP-PBX applications, MediaPack enhances remote location availability and provides Stand Alone Survivability (SAS) when there is no IP connection between branch locations and a central SIP server, SIP proxy or central IP-PBX
The MediaPack 1xx gateways are fully interoperable with leading softswitches, SIP servers and H.323 systems.
Features
- Support for 2 to 24 analog ports
- T.38 fax compliant
- Rich subscriber feature set: 3-way conference with local mixing, call pickup, hunt groups, call forwarding, call hold and call transfer
- Echo cancellation, jitter buffer, voice activity detection (VAD) and comfort noise generation (CNG)
- Complies with MGCP, H.323v4 and SIP control protocols
Benefits
- Leverage investment in existing analog telephone, modem, and fax systems – easing VoIP migration
- Lifeline for fallback to PSTN for E911 (Emergency number PSTN breakthrough) or upon network/power failure (FXO and/or FXS configurations)
- Standalone Survivability (SAS) keeps your business running in the event of a network failure
Specifications
| Design | |
|---|---|
| LED indicators | Yes |
| Safety | EN60950-1 |
| Certification | EN55022 , CFR, EN55024, EN61000-3-3, EN61000-3-2, VCCI Class X1 |
| Features | |
| Interface | 16 x FXS |
| Voice codecs | G.711, G.722, G.723.1, G.726, G.729A, G.729B |
| Performance | |
| Control display unit | Yes |
| Certification | EN55022 , CFR, EN55024, EN61000-3-3, EN61000-3-2, VCCI Class X1 |
| Protocols | |
| Management protocols | BootP, DHCP, TFTP, HTTP, DHCP, EMS, SNMP V3 |
| Network | |
| Cabling technology | 10/100Base-T(X) |
| Security | |
| Security algorithms | HTTPS, SRTP, SSL/TLS |
| Ports & interfaces | |
| Foreign eXchange Station (FXS) ports quantity | 16 |
| Interface | 16 x FXS |
| Ethernet LAN (RJ-45) ports | 1 |
| Power | |
| Input voltage | 100 - 240 V |
| Input frequency | 50/60 Hz |
| Weight & dimensions | |
| Weight | 1.8 kg |
| Dimensions (WxDxH) | 445 x 269 x 44 mm |
| Packaging content | |
| AC adapter included | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 40 °C |
| Storage temperature (T-T) | -20 - 85 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Technical details | |
| Interface | 16 x FXS |
| Voice codecs | G.711, G.722, G.723.1, G.726, G.729A, G.729B |
| AC adapter included | Yes |
| Indication | |
| LED indicators | Yes |
| Display | |
| Control display unit | Yes |
| Certificates | |
| Safety | EN60950-1 |
| Certification | EN55022 , CFR, EN55024, EN61000-3-3, EN61000-3-2, VCCI Class X1 |
