HPE Alletra Storage Server 4210 EDSFF Configure-to-order System

Alletra Storage Server 4210 EDSFF Configure-to-order System

Reasons To Buy

Delivered with an Automated, Intuitive Cloud Experience

Simplify and transform your data infrastructure operations with a cloud operational experience for your HPE Alletra Storage Server 4210. Whether purchased or consumed as-a-service, you can monitor and operate through intuitive fleet management SaaS and rich REST APIs.
Rather than owning and maintaining your server-based data infrastructure, you can simply use it as-a-service via GreenLake Flex Solution, freeing financial and people resources to focus on other critical areas of your business.
Simplify and secure server management from edge to cloud with HPE Compute Ops Management, an as-a-service compute management experience that delivers greater simplicity, agility, and speed across your entire HPE Alletra Storage Server 4000 portfolio.
Expanded DMTF Redfish APIs enable you to programmatically manage and automate tasks and bulk actions, reducing risks and demands on your limited IT resources particularly in large scale and geographically distributed deployments.

Built for Applications that Require High-Caliber Performance

Purposely engineered to achieve maximum performance from your data storage-intensive workloads, the HPE Alletra Storage Server 4210 provides more data throughput, data processing, and data capacity in a seamless-to-deploy yet high density 1U form factor.
The configurable front storage with optional twelve, sixteen, and twenty E3.S PCIe Gen5 NVMe SSD drive bays provide the flexibility to balance data capacity, system performance, and thermal efficiency.
The HPE Alletra Storage Server 4210 offers exceptional throughput with up to 150 GB/s (1200 Gbps) of network bandwidth into the system, up to 96 GT/s for data in flight through the system, and up to 315 GB/s of PCIe Gen5 bandwidth to All-NVMe SSDs.
Unlock value from your data faster with two Intel Xeon 6 processors totaling up to 288 cores, support for up to three GPU or FPGA accelerators capable of many trillions of operations per second, and up to 4 TB DDR5 memory at 6400 MT/s speed.

Next-Level End-to-End Security by Design

The HPE Alletra Storage Server 4210 is built with end-to-end security at its core, from silicon to software and factory to cloud. Protect your customers, your organization, and your data from increasingly sophisticated and dangerous threats.
A physical bezel lock, logical Configuration Lock, Secure Boot, FIPS 140-2 Self-Encrypting Drives (SEDs), and Secure Erase that meets NIST Guidelines for Media Sanitization secure your data throughout your infrastructure lifecycle to end-of-life decommissioning.
HPE iLO 7 supports quantum-resistant (PQC) algorithms and assigns HPE Alletra Storage Server 4210 firmware with algorithms approved by CNSA 2.0 to boost resilience against potential attacks by quantum computers.
The HPE Alletra Storage Server 4210, powered by Intel Xeon 6 processors, adds hardware- and software-assisted security features including Intel Software Guard Extensions (SGX) for application isolation and Trusted Domain Extensions (TDX) for VM isolation.

Description

Are you looking for a storage server with exceptional performance and capacity to accelerate your AI-driven initiatives? The HPE Alletra Storage Server 4210 is specifically designed for data storage-intensive workloads that require peak performance. Offering configuration flexibility that optimizes thermal efficiency, it will power your essential data-driven initiatives. From data stores for AI and real-time data analytics to distributed and NoSQL databases, performance sensitive Software-Defined Storage, and data heavy hyperconverged infrastructure, it delivers the capabilities you need at ideal economics with trusted security and a cloud operating experience. This includes the option to consume as-a-service via GreenLake Flex Solution enabling you to transition from owning and maintaining to simply utilizing. HPE Alletra Storage Server 4000 systems provide the data infrastructure needed for every data-driven organization.

What is new supporting point:
Support for up to three single-wide (SW) GPUs to unleash AI- driven data storage sever workloads.
HPE Integrated Lights-Out 7 (iLO 7) server management software with streamlined manageability through a redesigned GUI, Redfish API, and increased security via patented secure enclave technology.
Configurable modular front storage for up to twenty direct connect EDSFF PCIe Gen5 SSDs. All-NVMe design with up to 315 GB/s bandwidth in a 1U standard form factor.
Cloud operating experience built on GreenLake for simplified and automated lifecycle management including dramatically easier firmware management.
Multiple HPE cooling options increase performance and energy efficiency to support sustainability initiatives.
Dual Intel Xeon 6 processors drive greater performance along with DDR5 memory at speeds of up to 6400 MT/s with up to 14%^[1] more bandwidth for demanding data processing workloads.

Specifications

Storage
Supported RAID controllers	Optional Intel Virtual RAID on CPU (Intel VROC)
Ports & interfaces
Expansion slots	Up to 3 PCIe Gen5 slots and 2 OCP 3.0 slots
Design
Chassis type	Rack (1U)
Performance
Trusted Platform Module (TPM) version	2.0
Trusted Platform Module (TPM)	Yes
Security features	TPM 2.0, iDevID, Silicon Root of Trust, logical Configuration Lock, Secure Boot, Secure Start, optional Self-Encrypting Drives, optional Secure Erase, optional lockable security bezel, optional HPE Server Security Optimized Service
Management platform	Included - HPE iLO7 Standard with Intelligent Provisioning (embedded), HPE OneView Standard (download required). Optional - HPE iLO7 Advanced upgradable with license, HPE Compute Ops Management (subscription), and HPE OneView Advanced.
Management features
Management platform	Included - HPE iLO7 Standard with Intelligent Provisioning (embedded), HPE OneView Standard (download required). Optional - HPE iLO7 Advanced upgradable with license, HPE Compute Ops Management (subscription), and HPE OneView Advanced.
Technical details
Trusted Platform Module (TPM) version	2.0
Trusted Platform Module (TPM)	Yes
Security features	TPM 2.0, iDevID, Silicon Root of Trust, logical Configuration Lock, Secure Boot, Secure Start, optional Self-Encrypting Drives, optional Secure Erase, optional lockable security bezel, optional HPE Server Security Optimized Service
Chassis type	Rack (1U)
Other features
Security features	TPM 2.0, iDevID, Silicon Root of Trust, logical Configuration Lock, Secure Boot, Secure Start, optional Self-Encrypting Drives, optional Secure Erase, optional lockable security bezel, optional HPE Server Security Optimized Service
