ASUS ROG Strix G16 G614JV-N3153W Intel® Core™ i7 i7-13650HX Laptop 40.6 cm (16") WUXGA 16 GB DDR5-SDRAM 1 TB SSD NVIDIA GeForce RTX 4060 Wi-Fi 6E (802.11ax) Windows 11 Home Black, Green, Grey

Intel Core i7-13650HX (24MB Cache), 16GB DDR5-SDRAM, 1000GB SSD, 40.6 cm (16") WUXGA 1920 x 1200, Intel UHD Graphics, NVIDIA GeForce RTX 4060 (8GB GDDR6), LAN, WLAN, Webcam, Windows 11 Home 64-bit

Key Features

• 13th Gen Intel® Core™ i7-13650HX processor with 14 cores and 20 threads at up to 55W TDP
• NVIDIA GeForce RTX™ 4060 Laptop GPU with 140W max TGP with NVIDIA Advanced Optimus
• Dazzling 16-inch WUXGA 165Hz Nebula Display, 16:10 aspect ratio, 165Hz/7ms, and 100% sRGB
• Game with confidence thanks to Tri-Fan Technology, full-surround vents, and Conductonaut Extreme liquid metal
• Dolby Vision and Dolby Atmos support for immersive content

Reasons To Buy

Raise your game. Carry your squad.

Reach new heights of Windows 11 Pro Gaming performance with the Strix G16 and Strix G18, featuring up to an Intel® Core™ i9-13980HX processor and up to an NVIDIA® GeForce RTX™ 4080 Laptop GPU with a max TGP of 175W and a dedicated MUX Switch with NVIDIA Advanced Optimus. Sporting all new 16- and 18-inch Nebula displays and full-surround vents with Tri-Fan Technology, the 2023 ROG Strix G16 and Strix G18 are here to change the way you game.

Power up your play

Draw more frames and win more games with the brand new Strix G and Windows 11 Pro. Powered by up to a 13th Gen Intel® Core™ i9-13980HX Processor and up to an NVIDIA GeForce RTX 4080 Laptop GPU boasting a max TGP of 175W with Dynamic Boost, be ready to dominate the competition in all of the latest games. Backed up with a dedicated MUX Switch and NVIDIA Advanced Optimus, the Strix G unlocks the true potential of its hardware. With PCIe Gen4x4 SSD storage and up to 32GB of 4800MHz DDR5 RAM, large game libraries and intense multitasking sessions are a breeze for this gaming machine.

ROG Intelligent Cooling

To accommodate such powerful components, the Strix G’s chassis and motherboard were both redesigned to accommodate our new full-width heatsink, whose fins were moved even closer to the exhaust vents for more efficient cooling. The full-width heatsink is built from three different sections, surrounding the motherboard with densely-packed fins for a total surface area of 174,183-195,509mm², up to 92% increase from the 2022 Strix G series. This design maximizes the available pathing for hot air to escape the machine and drastically increases overall airflow.
Finally, most gaming laptops have a dual fan cooling system, but the Strix G was able to push the performance envelope even further with the introduction of a third fan that helps keep the GPU and VRAM cool. Paired with seven heatpipes and Conductonaut Extreme liquid metal on both the CPU and GPU* the Strix G’s cooling system is a marvel of engineering.
*Conductonaut Extreme liquid metal is applied to the GPU on models with an RTX™ 4080 GPU only

ROG Nebula Display

You can’t beat the enemy if you don’t see them coming. The Strix G has ultra-fast panel options for every scenario, making sure you’ll never miss a moment. For the first time ever, this 16- and 18-inch machine offer QHD 240Hz Nebula displays. A 16:10 panel with 500 nits of brightness, 100% DCI-P3 coverage and 3ms response times, the Strix G has pixel-perfect precision even in the most frenetic firefights. The Strix G is also available with a Full HD 165Hz panel, with each option offering fantastic color, Dolby Vision, Adaptive-Sync support, and an 89% screen-to-body ratio for a stellar gaming and viewing experience.

Designed to win. Built for victory.

The Republic of Gamers was built by those who love to play video games. All ROG designs come with gamers in mind, from the chassis, lighting integration, software controls, and macro functions. These ROG exclusive design features not only give you a competitive advantage, but they make sure you never blend in with the crowd.

Press the Attack

[4-zone]
The difference between victory and defeat can be separated by a single keystroke, so the Strix G has a full-size keyboard designed to secure the win. Overstroke technology offers sublime work and play, reducing key actuation and improving responsiveness. Built with gamers in mind, the keyboard features spaced function keys for intuitive identification and dedicated hotkeys for quick access to essential commands. The QWERASDF keys and space bar feature a semi-transparent design, allowing for easy identification even in low light scenarios. Large arrow keys allow for more accurate control in the heat of battle, while a larger touchpad means easier tracking across all of your applications. 4-zone RGB lighting lets you choose

Studio-quality Sound

Dual Dolby Atmos-powered speakers create an authentic sound stage for your games. Hi-Res audio ensures you hear your music in the same quality it was recorded. Two-Way AI Noise Cancelation processes both incoming and outgoing audio to filter any errant background noises, making sure that your calls, chats and streams come through without distraction.

All Day Endurance

The Strix G is ready to go the distance. Featuring a 90Wh battery, the laptop can easily browse the web for hours away from the wall before needing a recharge. For flexibility on the go, USB Type-C charging is supported up to 100W. When charging using the supplied 330W power adapter, the Strix G can recharge from zero to 50% in just 30 minutes.

Stay Connected

When you need to plug into the big screen, the dedicated GPU powers an HDMI 2.1 port for the latest TVs and monitors, increasing total bandwidth from 18 to 48Gbps, and supporting up to 4K 120Hz and 8K 60Hz content.  Two USB Type-C ports allow for plenty of connectivity—one for DisplayPort and power delivery, and a second with Thunderbolt 4 support.

Xbox Game Pass Ultimate

Play over 100 high-quality games with friends on your PC, console, phone or tablet for one low monthly price.* With games added all the time, there’s always something new to play.

Description

RAISE YOUR GAME. CARRY YOUR SQUAD.
Draw more frames and win more games with the brand new Strix G16 and Windows 11 Home. Powered by up to a 13th Gen Intel® Core™ i7-13650HX Processor and an NVIDIA GeForce RTX 4060 Laptop GPU boasting a max TGP of 140W with Dynamic Boost, be ready to dominate the competition in all of the latest games. Backed up with a dedicated MUX Switch and NVIDIA Advanced Optimus support, the Strix G16 unlocks the true potential of its hardware. With PCIe Gen4x4 SSD storage and up to 32GB of 4800MHz DDR5 RAM, large game libraries and intense multitasking sessions are a breeze for this gaming machine.

Specifications

Design
Colour name	Volt Green
Product type	Laptop
Market positioning	Gaming
Form factor	Clamshell
Product colour	Black, Green, Grey
Display
HD type	WUXGA
LED backlight	Yes
Display brightness	250 cd/m²
Display response rise/fall	7 ms
Contrast ratio (typical)	1000:1
Touchscreen	No
Display resolution	1920 x 1200 pixels
Display diagonal	40.6 cm (16")
Anti-glare screen	Yes
Maximum refresh rate	165 Hz
RGB colour space	sRGB
High Dynamic Range (HDR) technology	Dolby Vision
Colour gamut	100%
Native aspect ratio	16:10
High Dynamic Range (HDR) supported	Yes
Processor
Processor generation	13th gen Intel® Core™ i7
Bus type	DMI4
Configurable TDP-down	45 W
Processor cache	24 MB
Processor model	i7-13650HX
Processor boost frequency	4.9 GHz
Processor cores	14
Motherboard chipset	Intel HM770 Express
Processor manufacturer	Intel
Processor family	Intel® Core™ i7
Memory
Memory form factor	SO-DIMM
Internal memory	16 GB
Memory layout (slots x size)	2 x 8 GB
Internal memory type	DDR5-SDRAM
Memory clock speed	4800 MHz
Memory slots	2x SO-DIMM
Maximum internal memory	32 GB
Memory channels	Dual-channel
Storage
SSD form factor	M.2
Storage media	SSD
Optical drive type	No
Number of SSDs installed	1
SSD capacity	1 TB
SSD interface	PCI Express 4.0
Card reader integrated	No
Total storage capacity	1 TB
Total SSDs capacity	1 TB
NVMe	Yes
Graphics
Discrete graphics card	Yes
Discrete graphics card memory	8 GB
NVIDIA G-SYNC	Yes
On-board graphics card	Yes
On-board graphics card model	Intel® UHD Graphics
Discrete graphics card model	NVIDIA GeForce RTX 4060
Discrete graphics memory type	GDDR6
Discrete GPU manufacturer	NVIDIA
On-board GPU manufacturer	Intel
Audio
Audio system	Dolby Atmos
Number of built-in speakers	2
Built-in microphone	Yes
Camera
Front camera	Yes
Front camera resolution	1280 x 720 pixels
Front camera HD type	HD
Optical drive
Optical drive type	No
Network
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
Bluetooth	Yes
Bluetooth version	5.3
Antenna type	2x2
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
USB Type-C DisplayPort Alternate Mode	Yes
USB 2.0 ports quantity	0
HDMI ports quantity	1
HDMI version	2.1
Ethernet LAN (RJ-45) ports	1
Combo headphone/mic port	Yes
USB Power Delivery (USB PD)	Yes
Thunderbolt 4 ports quantity	1
Intel® Thunderbolt 4	Yes
Power adapter barrel connector	6.0 mm
DC-in jack	Yes
Performance
Motherboard chipset	Intel HM770 Express
Repairability index	8.6
Keyboard
Pointing device	Touchpad
Numeric keypad	No
Keyboard backlit	Yes
Keyboard backlit colour	RGB
Keyboard backlit zone	4-zone RGB
Software
Operating system architecture	64-bit
Trial software	McAfee 30 days, Xbox Game Pass Ultimate_3 months (*Terms and exclusions apply. Offer only available in eligible markets for Xbox Game Pass Ultimate. Eligible markets are determined at activation. Game catalog varies by region, device, and time.), 1-month trial for new Microsoft 365 customers. Credit card required.
Operating system installed	Windows 11 Home
Technical details
Market positioning	Gaming
Form factor	Clamshell
Product colour	Black, Green, Grey
Discrete graphics card memory	8 GB
Sustainability compliance	Yes
Sustainability certificates	ENERGY STAR
Repairability index	8.6
Processor special features
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Flex Memory Access	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Embedded options available	No
CPU configuration (max)	1
Intel Virtualization Technology (VT-x)	Yes
Battery
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	4
Battery capacity	90 Wh
Power
AC adapter power	280 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	14 A
AC adapter output voltage	20 V
USB Power Delivery (USB PD)	Yes
USB Type-C charging port	Yes
DC-in jack	Yes
Security
Password protection	Yes
Trusted Platform Module (TPM)	Yes
Password protection type	BIOS, User
Sustainability
Sustainability compliance	Yes
Sustainability certificates	ENERGY STAR
Weight & dimensions
Width	354 mm
Depth	264 mm
Height (front)	2.26 cm
Height (rear)	3.04 cm
Weight	2.5 kg
Packaging data
Package weight	4.21 kg
Package width	335 mm
Package height	420 mm
Package depth	106 mm
AC adapter included	Yes
Packaging content
AC adapter included	Yes
Other features
On-board graphics card	Yes
Audio system	Dolby Atmos
AC adapter included	Yes
Anti-glare screen	Yes
