Lenovo ThinkStation P620 AMD Ryzen Threadripper PRO 5965WX 64 GB DDR4-SDRAM 1 TB SSD Windows 11 Pro Tower Workstation Black

AMD Ryzen Threadripper PRO 5965WX (24C/48T, 3.8/4.5GHz, 12MB L2/128MB L3), 4x 16GB RDIMM DDR4-3200 ECC, 1x 1TB SSD M.2 2280 PCIe 4.0 NVMe Opal, Windows 11 Pro 64

Key Features

• AMD Ryzen Threadripper PRO 5965WX (24C/48T, 3.8/4.5GHz, 12MB L2/128MB L3)
• 4x 16GB RDIMM DDR4-3200 ECC
• 1x 1TB SSD M.2 2280 PCIe 4.0 NVMe Opal
• Windows 11 Pro 64

Reasons To Buy

Power that can’t be beat

This AMD technology gives the P620 up to 64 cores and 128 threads—all from a single CPU. Simply put, other workstations would need at least two CPUs to accomplish what the P620 with AMD Ryzen™ Threadripper™ PRO can do with one.

Highly configurable
The ThinkStation P620 workstation tower is equipped with abundant storage and memory capacity, numerous expansion slots, enterprise-class AMD Ryzen PRO manageability, and security features. With unprecedented NVIDIA® graphics support, this eminently configurable workstation is equipped with up to two NVIDIA® RTX™ A6000, up to two NVIDIA® Quadro RTX™ 8000, or up to four NVIDIA® Quadro RTX™ 4000 GPUs.

Cool & accessible

An air-cooled thermal system helps ensure the ThinkStation P620 tower runs well in any location, allowing the CPUs and GPUs to stay cool while running at peak performance until the job is done. What’s more, tool-less accessibility to the chassis enables easy upgrades if needed.

Handles complex workloads with ease

With independent software vendor (ISV) certifications, the P620 workstation works across the full range of industry verticals including Architecture, Engineering, & Construction, Media & Entertainment, Healthcare / Life Science, Oil & Gas / Energy, Finance, and AI / VR. It’s perfect for multithreaded compute-intensive applications used by architects, engineers, scientists, geophysicists, and more. Learn more about specific ISV certifications.

Seamless security. Smarter security.

ThinkShield, our built-in suite of security solutions, keeps your ThinkStation P620 tower and your critical data safe. The Trusted Platform Module (TPM) firmware uses encryption to significantly decrease the possibility of hacking. You can relax knowing that serial, parallel, USB, audio, and network ports can all be disabled. Plus, set up a BIOS password as well as a power-on password to ensure access remains restricted. For additional physical security, choose the optional Side-Cover Key Lock Kit to prevent access to the system.

Description

Game-changing power. Limitless possibilities.
- Powered by AMD Ryzen™ Threadripper™ PRO
- Supports choice of Windows and Linux operating systems
- 2 NVIDIA® RTX™ A6000 graphic cards
- Combines legendary reliability & innovation with professional manageability and enterprise-class support
- Performance-tuned and ISV-certified for multithreaded application environments
- Best in class air-cooled thermal system
- Built-in suite of security solutions
- Perfect for architects, engineers, scientists, geophysicists, and more

Specifications

Processor
Processor generation	AMD Ryzen Threadripper PRO 5000 WX-Series
Processor cache type	L3
Processor cache	128 MB
Processor frequency	3.8 GHz
Processor model	5965WX
Number of processors installed	1
Processor manufacturer	AMD
Processor boost frequency	4.5 GHz
Processor threads	48
Processor cores	24
Processor family	AMD Ryzen Threadripper PRO
Memory
ECC	Yes
Memory layout (slots x size)	4 x 16 GB
Internal memory	64 GB
Maximum internal memory	1.02 TB
Memory slots	8x DIMM
Internal memory type	DDR4-SDRAM
Memory clock speed	3200 MHz
Memory channels	Octa-channel
Storage
Storage media	SSD
Optical drive type	No
SSD interface	NVMe, PCI Express 4.0
SSD capacity	1 TB
Number of SSDs installed	1
Total storage capacity	1 TB
SSD form factor	M.2
Total SSDs capacity	1 TB
NVMe	Yes
Graphics
Discrete graphics card	No
On-board graphics card	No
Discrete graphics card model	Not available
On-board graphics card model	Not available
Optical drive
Optical drive type	No
Network
Ethernet LAN	Yes
Wi-Fi	No
Bluetooth	No
Ethernet LAN data rates	100,1000,2500,10000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
LAN controller	Marvell AQtion AQN-107
Ports & interfaces
Combo headphone/mic port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	6
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
Thunderbolt 3 ports quantity	0
USB 2.0 ports quantity	2
PS/2 ports quantity	2
Microphone in	Yes
Line-out	Yes
Line-in	Yes
Headphone outputs	1
HDMI ports quantity	0
Ethernet LAN (RJ-45) ports	1
Expansion slots
PCI Express x16 (Gen 4.x) slots	4
PCI Express x8 (Gen 4.x) slots	2
Technical details
Cable lock slot type	Kensington
Product type	Workstation
Trusted Platform Module (TPM)	Yes
Product colour	Black
Chassis type	Tower
Audio system	High Definition Audio
Placement supported	Vertical
Number of 5.25" bays	1
Number of 3.5" bays	2
Cable lock slot	Yes
Motherboard chipset	AMD WRX80
Sustainability certificates	ENERGY STAR, EPEAT Silver, GREENGUARD
Compliance certificates	RoHS
Design
Volume	33 L
Cable lock slot type	Kensington
Product colour	Black
Chassis type	Tower
Placement supported	Vertical
Number of 5.25" bays	1
Number of 3.5" bays	2
Cable lock slot	Yes
Colour name	Black
Performance
Audio chip	Realtek ALC4050H
Password protection	Yes
Password protection type	Power on, Supervisor
Product type	Workstation
Trusted Platform Module (TPM)	Yes
Audio system	High Definition Audio
Motherboard chipset	AMD WRX80
Software
Operating system language	English
Operating system architecture	64-bit
Operating system installed	Windows 11 Pro
Power
Power supply	1000 W
Operational conditions
Operating altitude	0 - 3048 m
Storage temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	10 - 35 °C
Non-operating altitude	0 - 12192 m
Certificates
Certification	EPEAT Silver ENERGY STAR 8.0 (on model 30E00006US) GREENGUARD RoHS compliant
Compliance certificates	RoHS
Sustainability
Sustainability certificates	ENERGY STAR, EPEAT Silver, GREENGUARD
Weight & dimensions
Volume	33 L
Width	165 mm
Depth	455 mm
Height	446 mm
Weight	24 kg
Packaging content
Mouse included	Yes
Keyboard included	Yes
Other features
Trusted Platform Module (TPM)	Yes
On-board graphics card	No
Processor manufacturer	AMD
