Vertiv Liebert Edge Uninterruptible Power Supply (UPS) - 1000VA 900W 230V 1U Line Interactive AVR Rack Mount | 0.9 PF

Edge UPS - 1000VA 900W 230V 1U Line Interactive AVR Rack Mount Battery Backup Single Phase|0.9 PF(EDGE-1000IRM1U)

Key Features

• 1000VA UPS with advanced AVR for a more stable output voltage regulation
• This line interactive UPS has 0.9 output power factor ensuring more active power to protect larger loads
• Get similar features as a 2U battery backup in a compact 1U rack space
• Add a communication card to this single phase UPS to manage devices remotely
• Get 6 total outlets with 3 programmable outlets to prioritize critical loads and achieve longer runtime

Description

The Vertiv Edge uninterruptible power supply (UPS) is designed to protect server and networking equipment in distributed and Edge IT applications. With compact 1U rack format, this 1000VA UPS offers reliable protection from downtime and damage caused by power spikes, swells and brownouts. Automatic Voltage Regulation (AVR) extends battery life and safeguards critical equipment. With sine wave output, this line interactive UPS ensures availability of network closets and Edge data centers. It operates at up to 98% efficiency in normal operation mode, providing energy savings. Add optional Vertiv Intellislot SNMP/Webcards for remote power management and OS's shutdown with free Vertiv Power Assist software. The Edge family has a wide range of power ratings, from 500VA up to 3000VA and form factors, such as mini-tower, 1U rack and rack/tower. It is easy to install, configure and operate and comes with an intuitive, color LCD screen.

Specifications

Power
Output power	900 W
Input operation voltage (min)	166 V
Input operation voltage (max)	278 V
Output operation voltage (min)	200 V
Output operation voltage (max)	240 V
Surge energy rating	624 J
Efficiency	97%
Output power capacity	1 kVA
Ports & interfaces
Cable length	3 m
Emergency Power Off (EPO) connector	Yes
USB port	Yes
AC outlets quantity	3 AC outlet(s)
AC outlet types	C13 coupler
Power plug	C14 coupler
Performance
UPS topology	Line-Interactive
Waveform	Pure sine
Features
Country of origin	China
UPS topology	Line-Interactive
Waveform	Pure sine
Output power	900 W
Input operation voltage (min)	166 V
Input operation voltage (max)	278 V
Output operation voltage (min)	200 V
Output operation voltage (max)	240 V
Surge energy rating	624 J
Efficiency	97%
Output power capacity	1 kVA
Input frequency	45/65 Hz
Battery
Battery recharge time	3 h
Design
Country of origin	China
Rack capacity	1U
Form factor	Rackmount
Product colour	Black
Safety	IEC/EN62040-1
Certification	CE, CB Report, EAC, RCM, UKCA
Cable length	3 m
Display type	LCD
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-25 - 55 °C
Operating relative humidity (H-H)	20 - 90%
Operating altitude	0 - 3000 m
Technical details
Compliance certificates	RoHS
Weight & dimensions
Package width	570 mm
Package depth	700 mm
Package height	200 mm
Weight	16 kg
Width	438 mm
Package weight	23 kg
Height	43 mm
Depth	480 mm
Packaging data
Package width	570 mm
Package depth	700 mm
Package height	200 mm
Package weight	23 kg
Logistics data
Shipping (inner) case width	57 cm
Shipping (inner) case length	70 cm
Shipping (inner) case height	20 cm
Shipping (inner) case gross weight	23.4 kg
Certificates
Safety	IEC/EN62040-1
Certification	CE, CB Report, EAC, RCM, UKCA
