Vertiv Liebert GXT5 Double Online Conversion UPS - 750VA/750W | 230V | With Rackmount Kit and Intellislot RDU101 Communication Card | GXT5-750IRT2UXLN

2U Rack/Tower | 8.50 Minute Stand-by | 200 V AC, 208 V AC, 220 V AC Output | 8 x IEC 60320 C13 Receptacle(s) | Single Phase | Sine Wave | Serial Port | SNMP/HTTP Remote Monitoring | 5-year Warranty (3-year Standard Warranty + 2-year Extended Warranty)

Key Features

• It offers reliable, easy-to-manage power protection and battery backup with 750VA(750W) capacity.
• It has UNITY Power Factor (1.0) for more usable power and more connected loads to save space and costs.
• It includes a built-in Vertiv RDU101 network communications card for remote management.
• It comes with a Vertiv 3-year warranty plus a 2-year extension for a total of 5 years in coverage.
• It is ENERGY STAR® 2.0 certified with higher efficiency, for energy savings and improved reliability.

Description

The Vertiv Liebert GXT5 UPS 750VA/750W is a 2U UPS solution that ensures the health and availability of IT infrastructure. With online, double conversion technology, the UPS protects critical equipment against outages and every type of power disturbance without drawing on battery power, extending battery life and minimizing replacements. This can support a wide range of power environments, including 200/208/220/230/240V user configurable AC power, and has scalable runtime options with matching external battery cabinets to offer extra time during an outage to support critical equipment and activity. This unit has a built-in Vertiv RDU101 communications card for remote monitoring to help you make more informed decisions and faster event resolution. It includes hot-swappable batteries and all hardware for installing it as a tower or in an equipment rack. This single-phase UPS is ENERGY STAR® 2.0 certified and offers leading normal mode power efficiency and Eco-mode for ultimate efficiency levels. It comes with a 5-year warranty (3-year factory warranty plus 2-year extended warranty). This promotion is subject to the Distributor’s product availability and is only available while product stocks last. Vertiv reserves the right to provide a 1-month notice to terminate the offer. This offer is not available in conjunction with any other offer/discount.

Specifications

Power
Output voltage regulation	3%
Input power factor	0.99
Output power	750 W
Input operation voltage (min)	115 V
Input operation voltage (max)	288 V
Output operation voltage (min)	200 V
Output operation voltage (max)	240 V
Efficiency	95%
Emergency Power Off (EPO)	Yes
Output power capacity	0.75 kVA
Battery
Battery type	VRLA
Battery capacity	9 VAh
Battery voltage	12 V
Battery technology	Sealed Lead Acid (VRLA)
Battery recharge time	3 h
Typical backup time at half load	16.3 min
Typical backup time at full load	5.6 min
Hot-swap battery	Yes
Performance
UPS topology	Double-conversion (Online)
Waveform	Pure sine
Number of input phases	1
Response time	0 ms
Power protection features	Overload
Noise level	46 dB
Audible alarm(s)	Yes
Features
Output frequency	50/60 Hz
UPS topology	Double-conversion (Online)
Waveform	Pure sine
Output voltage regulation	3%
Number of input phases	1
Input power factor	0.99
Response time	0 ms
Output power	750 W
Input operation voltage (min)	115 V
Input operation voltage (max)	288 V
Output operation voltage (min)	200 V
Output operation voltage (max)	240 V
Efficiency	95%
Emergency Power Off (EPO)	Yes
Power protection features	Overload
Noise level	46 dB
Audible alarm(s)	Yes
Output power capacity	0.75 kVA
Input frequency	40 - 70 Hz
Ports & interfaces
Emergency Power Off (EPO) connector	Yes
USB port	Yes
Serial interface type	RS-232, RS-485
AC outlets quantity	8 AC outlet(s)
AC outlet types	C13 coupler, C19 coupler
Serial ports quantity	1
Design
International Protection (IP) code	IP20
Rack capacity	2U
Form factor	Rackmount/Tower
Product colour	Black
Safety	IEC62040-1:2008, GS; UL1778, c-UL
Certification	IEC/EN/AS 62040-2 2nd Ed (Cat 2 – 6); FCC 15 A CISPR22 A(RFI)
Display type	LCD
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 40 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 3000 m
Technical details
Output frequency	50/60 Hz
Bypass	Yes
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	85078000
Compliance certificates	RoHS
Packaging data
Package dimensions (WxDxH)	517 x 617 x 262 mm
Quick installation guide	Yes
Cables included	USB cable
Manual	Yes
Package width	517 mm
Package depth	617 mm
Package height	262 mm
Package weight	21 kg
Certificates
Certification	IEC/EN/AS 62040-2 2nd Ed (Cat 2 – 6); FCC 15 A CISPR22 A(RFI)
Compliance certificates	RoHS
Safety	IEC62040-1:2008, GS; UL1778, c-UL
Packaging content
Quick installation guide	Yes
Cables included	USB cable
Manual	Yes
Sustainability
Sustainability certificates	ENERGY STAR
Safety regulation & standards
Safety	IEC62040-1:2008, GS; UL1778, c-UL
Weight & dimensions
Package width	517 mm
Package depth	617 mm
Package height	262 mm
Weight	21 kg
Width	430 mm
Package weight	21 kg
Height	85 mm
Depth	400 mm
Logistics data
Harmonized System (HS) code	85078000
Other features
Battery type	VRLA
Output connections	IEC320 C13
Input connection type	C14
Dimensions (WxDxH)	430 x 400 x 85 mm
Package dimensions (WxDxH)	517 x 617 x 262 mm
Overload protection	Yes
Nominal output voltage	230 V
Nominal input voltage	230 V
Non-operating relative humidity (non-condensing)	0 - 95%
Bypass	Yes
