APC Easy PDU Metered 1U 16A 230V (8)C13

Easy PDU Metered 1U 16A 230V (8)C13

Key Features

• input: 1PH, 16A, 200-240VAC
• Outlets: (8) C13
• Metered
• Full-featured network management capability
• Interactive LCD display

Description

Schneider Easy Metered Rack PDU EPDU2016M is Easy-to-install and easy-to-use PDU, making rack power distribution easy and intelligent. This provides real-time remote monitoring, power management of connected loads, and much more features than the average power strip. EPDU2016M has IEC 60320 C20 200-240V type inlet and eight IEC C13 type outlet sockets. This is horizontal rack mountable PDU in ultra light weight and smart, multifunctional new designed display. Full-featured user friendly network management web interface provides standards-based management via Web, SNMP, and Command Line Interface. Allows users to access, configure, and manage units from remote locations to save valuable time. Indicates overload and warning conditions based on the user-defined alarm thresholds. Alerts users of potential overloaded circuits. Quickly and easily upgrade firmware via network download for future product enhancements. Eliminates the need to replace products already installed in the field when new features are released. The green packaging includes cable, installation guide, user manual and horizontal mounting brackets for quick and easy mounting in the rear of the enclosure. This can operate from -5° to +50°C temperation range and comes with 2 year of standard warranty. Define alarm thresholds in order to avoid overloaded circuits. Network and visual alarms inform the user of possible problems.

Specifications

Design
Type	Single-phase
PDU types	Metered
Mounting	Vertical
Product colour	Black
Rack capacity	1U
Ports & interfaces
AC outlets quantity	8 AC outlet(s)
AC outlet types	C13 coupler
Power plug	C13 coupler
Power
Nominal input voltage	230 V
Nominal output voltage	208 V
Output voltage	208 V
Maximum current	16 A
Load capacity	3680 VA
AC input frequency	50/60 Hz
Number of phases	1
Certificates
Compliance certificates	CE, UKCA
Operational conditions
Operating temperature (T-T)	-5 - 50 °C
Storage temperature (T-T)	-25 - 65 °C
Storage relative humidity (H-H)	5 - 95%
Operating relative humidity (H-H)	5 - 95%
Operating altitude	0 - 3000 m
Weight & dimensions
Weight	1.7 kg
Width	482 mm
Depth	100 mm
Height	44 mm
Package width	210 mm
Package depth	570 mm
Package height	680 mm
Package weight	3 kg
Packaging data
Package width	210 mm
Package depth	570 mm
Package height	680 mm
Package weight	3 kg
Technical details
Total carbon footprint (kg of CO2e)	649
Compliance certificates	CE, UKCA
Logistics data
Total carbon footprint (kg of CO2e)	649
