Cisco Aironet 1832I-E-K9 Wi-Fi Access Point, 802.11ac Wave 2, with Internal Antenna (AIR-AP1832I-E-K9)

Aironet 1832I-E-K9 Wi-Fi Access Point, 802.11ac Wave 2, with Internal Antenna (AIR-AP1832I-E-K9)

Key Features

• MU-MIMO: 802.11ac Wave 2 with 3x3 Multiple-Input Multiple-Output (MIMO) technology with two spatial streams when operating in single-user or multi-user MIMO mode, offering 867 Mbps rates for more capacity and reliability than competing access points
• APPLICATION VISIBILITY AND CONTROL: Network Based Application Recognition (NBAR) deep-packet inspection technology provides application-aware control on a wireless network and enhances manageability and productivity. It also extends Cisco’s Application Visibility and Control (AVC) as an end-to-end solution, which gives a complete visibility of applications in the network and allows the administrator to take some action on the same.
• RADIO RESOURCE MANAGEMENT: Cisco's Radio Resource Management (abbreviated RRM) allows Cisco's Unified WLAN Architecture to continuously analyse the existing RF environments, automatically adjusting each AP's power and channel configurations to help mitigate things such as co-channel interference and signal coverage problems. RRM reduces the need to perform exhaustive site surveys, increases system capacity and provides automated self-healing functionality to compensate for RF dead zones and AP failures
• SECURITY: Securing the Device: Cisco Umbrella (OpenDNS), Identity PSK (iPSK), IP and DNS ACLs. Securing the Air: Spectrum Intelligence, Wireless Intrusion Detection (WIDS). Securing the Network: 802.1x on AP, AAA profiling and policy
• PEACE OF MIND: Limited lifetime hardware warranty

Description

The Cisco Aironet 1832I, with IEEE’s 802.11ac Wave 2 support, offers a data rate of up to 867 Mbps on a 5-GHz radio, enabling a total aggregated dual-radio data rate of up to 1 Gbps. Ideal for small and medium-sized networks, the Aironet 1832Ii delivers industry-leading performance for highly secure and reliable wireless connections and provides a superior mobility end-user experience.

Specifications

Data transmission
Ethernet LAN data rates	10,100,1000 Mbit/s
Maximum data transfer rate	866.7 Mbit/s
Performance
2.4 GHz	Yes
5 GHz	Yes
Wi-Fi Multimedia (WMM)/(WME)	Yes
Country of origin	Mexico
Frequency band	2.4 - 5 GHz
Receiver sensitivity	802.11b (CCK) -101 dBm @ 1 Mbps -98 dBm @ 2 Mbps -92 dBm @ 5.5 Mbps -89 dBm @ 11 Mbps 802.11g (non HT20) -96 dBm @ 6 Mbps -95 dBm @ 9 Mbps -94 dBm @ 12 Mbps -92 dBm @ 18 Mbps -88 dBm @ 24 Mbps -85 dBm @ 36 Mbps ◦ -81 dBm @ 48 Mbps ◦ -79 dBm @ 54 Mbps 802.11a (non HT20) -96 dBm @ 6 Mbps -95 dBm @ 9 Mbps -94 dBm @ 12 Mbps -92 dBm @ 18 Mbps -88 dBm @ 24 Mbps -85 dBm @ 36 Mbps -80 dBm @ 48 Mbps -79 dBm @ 54 Mbps 2.4 GHz 802.11n (HT20) -96 dBm @ MCS0 -93 dBm @ MCS1 -90 dBm @ MCS2 -87 dBm @ MCS3 -84 dBm @ MCS4 -79 dBm @ MCS5 -78 dBm @ MCS6 -76 dBm @ MCS7 -93 dBm @ MCS8 -90 dBm @ MCS9 -87 dBm @ MCS10 -84 dBm @ MCS11 -81 dBm @ MCS12 -76 dBm @ MCS13 -75 dBm @ MCS14 -73 dBm @ MCS15 5 GHz 802.11n (HT20) -96 dBm @ MCS0 -92 dBm @ MCS1 -90 dBm @ MCS2 -86 dBm @ MCS3 -83 dBm @ MCS4 -79 dBm @ MCS5 -77 dBm @ MCS6 -76 dBm @ MCS7
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates	10,100,1000 Mbit/s
Channels quantity	25 channels
Maximum data transfer rate	866.7 Mbit/s
Internal memory	1024 MB
Flash memory	256 MB
Wireless LAN features
Frequency band	2.4 - 5 GHz
Channels quantity	25 channels
Network
Internal	No
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Memory
Internal memory	1024 MB
Flash memory	256 MB
Features
2.4 GHz	Yes
5 GHz	Yes
Wi-Fi Multimedia (WMM)/(WME)	Yes
Frequency band	2.4 - 5 GHz
Receiver sensitivity	802.11b (CCK) -101 dBm @ 1 Mbps -98 dBm @ 2 Mbps -92 dBm @ 5.5 Mbps -89 dBm @ 11 Mbps 802.11g (non HT20) -96 dBm @ 6 Mbps -95 dBm @ 9 Mbps -94 dBm @ 12 Mbps -92 dBm @ 18 Mbps -88 dBm @ 24 Mbps -85 dBm @ 36 Mbps ◦ -81 dBm @ 48 Mbps ◦ -79 dBm @ 54 Mbps 802.11a (non HT20) -96 dBm @ 6 Mbps -95 dBm @ 9 Mbps -94 dBm @ 12 Mbps -92 dBm @ 18 Mbps -88 dBm @ 24 Mbps -85 dBm @ 36 Mbps -80 dBm @ 48 Mbps -79 dBm @ 54 Mbps 2.4 GHz 802.11n (HT20) -96 dBm @ MCS0 -93 dBm @ MCS1 -90 dBm @ MCS2 -87 dBm @ MCS3 -84 dBm @ MCS4 -79 dBm @ MCS5 -78 dBm @ MCS6 -76 dBm @ MCS7 -93 dBm @ MCS8 -90 dBm @ MCS9 -87 dBm @ MCS10 -84 dBm @ MCS11 -81 dBm @ MCS12 -76 dBm @ MCS13 -75 dBm @ MCS14 -73 dBm @ MCS15 5 GHz 802.11n (HT20) -96 dBm @ MCS0 -92 dBm @ MCS1 -90 dBm @ MCS2 -86 dBm @ MCS3 -83 dBm @ MCS4 -79 dBm @ MCS5 -77 dBm @ MCS6 -76 dBm @ MCS7
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates	10,100,1000 Mbit/s
Channels quantity	25 channels
Maximum data transfer rate	866.7 Mbit/s
Internal memory	1024 MB
Flash memory	256 MB
Security
Security algorithms	802.1x RADIUS, AES, TKIP, WPA, WPA2
Ports & interfaces
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
DC-in jack	Yes
Power
Power plug type	Type C
Power consumption (typical)	15.4 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Design
Placement	Ceiling, Table, Wall
Country of origin	Mexico
Product colour	White
Internal	No
LED indicators	Yes
Antenna
Antennas quantity	3
Antenna gain level (max)	5 dBi
Antenna direction type	Omni-directional
Antenna features	Integrated antenna
Technical details
Receiver sensitivity	802.11b (CCK) -101 dBm @ 1 Mbps -98 dBm @ 2 Mbps -92 dBm @ 5.5 Mbps -89 dBm @ 11 Mbps 802.11g (non HT20) -96 dBm @ 6 Mbps -95 dBm @ 9 Mbps -94 dBm @ 12 Mbps -92 dBm @ 18 Mbps -88 dBm @ 24 Mbps -85 dBm @ 36 Mbps ◦ -81 dBm @ 48 Mbps ◦ -79 dBm @ 54 Mbps 802.11a (non HT20) -96 dBm @ 6 Mbps -95 dBm @ 9 Mbps -94 dBm @ 12 Mbps -92 dBm @ 18 Mbps -88 dBm @ 24 Mbps -85 dBm @ 36 Mbps -80 dBm @ 48 Mbps -79 dBm @ 54 Mbps 2.4 GHz 802.11n (HT20) -96 dBm @ MCS0 -93 dBm @ MCS1 -90 dBm @ MCS2 -87 dBm @ MCS3 -84 dBm @ MCS4 -79 dBm @ MCS5 -78 dBm @ MCS6 -76 dBm @ MCS7 -93 dBm @ MCS8 -90 dBm @ MCS9 -87 dBm @ MCS10 -84 dBm @ MCS11 -81 dBm @ MCS12 -76 dBm @ MCS13 -75 dBm @ MCS14 -73 dBm @ MCS15 5 GHz 802.11n (HT20) -96 dBm @ MCS0 -92 dBm @ MCS1 -90 dBm @ MCS2 -86 dBm @ MCS3 -83 dBm @ MCS4 -79 dBm @ MCS5 -77 dBm @ MCS6 -76 dBm @ MCS7
Products per shipping (inner) case	1 pc(s)
Harmonized System (HS) code	85176990
Indication
LED indicators	Yes
Weight & dimensions
Width	210.8 mm
Depth	210.8 mm
Weight	930 g
Height	50.8 mm
Package width	225.6 mm
Package depth	244.6 mm
Package height	98.6 mm
Package weight	1.48 kg
Packaging data
Package width	225.6 mm
Package depth	244.6 mm
Package height	98.6 mm
Package weight	1.48 kg
Operational conditions
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-30 - 70 °C
Storage relative humidity (H-H)	10 - 90%
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4572 m
Logistics data
Products per master (outer) case	1 pc(s)
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
