Cisco | SKU:
AIR-ANT2544V4M-RS=
22% off
Cisco Aironet Dual-Band Omnidirectional Wi-Fi Antenna, 4 dBi (2.4 GHz)/4 dBi (5 GHz), 4 Ports, Wall/Mast Mount, 1-Year Limited Hardware Warranty (AIR-ANT2544V4M-RS=)
€653.96
€836.65
Unit price
/
Unavailable
Shipping calculated at checkout.
Cisco Aironet Dual-Band Omnidirectional Wi-Fi Antenna, 4 dBi (2.4 GHz)/4 dBi (5 GHz), 4 Ports, Wall/Mast Mount, 1-Year Limited Hardware Warranty (AIR-ANT2544V4M-RS=) is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Delivery and Shipping
Delivery and Shipping
Products shipped within 2 working days from date of order.
Costs
0-24.99kg €14.50
25kg – 50kg €35.00
50kg and Up €60.00
No Customs Charges
No Customs Charges
Deliveries from Ireland & EU meaning no unwanted customs charges. No hidden charges.
Aironet Dual-Band Omnidirectional Wi-Fi Antenna, 4 dBi (2.4 GHz)/4 dBi (5 GHz), 4 Ports, Wall/Mast Mount, 1-Year Limited Hardware Warranty (AIR-ANT2544V4M-RS=)
Key Features
- OMNIDIRECTIONAL WI-FI ANTENNA: 4 dBi (2.4 GHz)/4 dBi (5 GHz); 4 dual-band ports; designed for dual-band port access points such as the Aironet 1830, 1850, 2800 and 3800 Series and Cisco Catalyst 9115AX, 9120AX and 9130AX Series
- CONNECTION AND MOUNT: 4 plenum-rated pigtail cables with 4 RP-TNC connectors; wall or mast mount
- 360-DEGREE RADIATION PATTERN: Intended for deployment when coverage in all directions from the antenna is required
- PERFORMANCE: Designed for improved coverage
- PEACE OF MIND: 1-year limited hardware warranty
Description
The Cisco Aironet AIR-ANT2544V4M-RS= Dual-Band Omnidirectional Wi-Fi Antenna is designed with improved performance in mind. It provides a 360-degree radiation pattern and is intended for deployment when coverage in all directions is required. This FCC-approved omnidirectional antenna includes circuitry to enable self-identification of the antenna by the Cisco Catalyst 9100 Access Points.Specifications
| Performance | |
|---|---|
| Antenna gain level (max) | 4 dBi |
| Networking standards | IEEE 802.11n |
| Frequency band | 2.4/5 GHz |
| Impedance | 50 Ω |
| Antenna gain (5 GHz) | 4 dBi |
| Antenna gain (2.4 GHz) | 4 dBi |
| Features | |
| Connector gender | Male |
| Antenna type | Omni-directional antenna |
| Voltage Standing Wave Ratio (VSWR) | < 2:1 |
| Purpose | Indoor & outdoor |
| Polarization | Vertical polarization |
| Mounting | Wall/Pole |
| Product colour | White |
| Cable length | 2.4 m |
| Antenna connector type | RP-TNC |
| Compatible products | Cisco Aironet 1600e, 2600e, 3600e |
| Country of origin | Malaysia |
| Antenna gain level (max) | 4 dBi |
| Networking standards | IEEE 802.11n |
| Frequency band | 2.4/5 GHz |
| Impedance | 50 Ω |
| Antenna gain (5 GHz) | 4 dBi |
| Antenna gain (2.4 GHz) | 4 dBi |
| Operational conditions | |
| Operating temperature (T-T) | -30 - 70 °C |
| Packaging data | |
| Package width | 215.9 mm |
| Package depth | 387.4 mm |
| Package height | 215.9 mm |
| Package weight | 1.41 kg |
| Technical details | |
| Antenna gain level (max) | 4 dBi |
| Frequency band | 2.4/5 GHz |
| Antenna type | Omni-directional antenna |
| Voltage Standing Wave Ratio (VSWR) | < 2:1 |
| Purpose | Indoor & outdoor |
| Polarization | Vertical polarization |
| Mounting | Wall/Pole |
| Impedance | 50 Ω |
| Cable length | 2.4 m |
| Antenna gain (5 GHz) | 4 dBi |
| Antenna gain (2.4 GHz) | 4 dBi |
| Antenna connector type | RP-TNC |
| Compatible products | Cisco Aironet 1600e, 2600e, 3600e |
| Harmonized System (HS) code | 85177100 |
| Network | |
| Networking standards | IEEE 802.11n |
| Colour | |
| Product colour | White |
| Weight & dimensions | |
| Package width | 215.9 mm |
| Package depth | 387.4 mm |
| Package height | 215.9 mm |
| Package weight | 1.41 kg |
| Packaging content | |
| Quick installation guide | Yes |
| Mounting kit | Yes |
| Manual | Yes |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| Country of origin | Malaysia |
| Quantity per pack | 1 pc(s) |
| Harmonized System (HS) code | 85177100 |
