Description
The UPS’s output power factor is 1, which means it is capable of connecting to more critical loads than conventional UPS. It also features Battery Management Technology to help batteries obtain optimal life span by balancing battery string voltage. Two-phase battery charging can charge the battery quickly and safely. The hot-swappable battery packs allow for easy maintenance without power interruption. Its multi-functional matrix LCD supports intuitive operation and quick configuration. The LCD panel is also rotatable to meet installation requirements.,
Power | |
---|---|
Output power | 2200 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
Output power capacity | 2.2 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 2.4 m |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 8 AC outlet(s) |
AC outlet types | C13 coupler, C19 coupler |
Power plug | C20 coupler |
USB 2.0 ports quantity | 1 |
Serial ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 2 |
Performance | |
Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of input phases | 1 |
Response time | 4 ms |
LED indicators | Error, Operation |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload |
Noise level | 57.5 dB |
Audible alarm(s) | Yes |
Features | |
Output frequency | 50/60 Hz |
Management protocols | SNMP/HTTP |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of input phases | 1 |
Response time | 4 ms |
Output power | 2200 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload |
Noise level | 57.5 dB |
Audible alarm(s) | Yes |
Output power capacity | 2.2 kVA |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Battery | |
Number of batteries supported | 4 |
Battery technology | Sealed Lead Acid (VRLA) |
Typical backup time at half load | 11.2 min |
Typical backup time at full load | 3.2 min |
Hot-swap battery | Yes |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Error, Operation |
Product colour | Black |
Certification | CE , FCC Class B , UL , RCM , VCCI |
Cable length | 2.4 m |
Housing material | Metal |
Display type | LCD |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Bypass | GreenPower UPS |
Sustainability certificates | ENERGY STAR |
Harmonized System (HS) code | 8504408590 |
Compliance certificates | RoHS |
Management features | |
Management protocols | SNMP/HTTP |
Weight & dimensions | |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Weight | 34.4 kg |
Width | 433 mm |
Package weight | 42.5 kg |
Height | 86.5 mm |
Depth | 500 mm |
Packaging data | |
Cables included | Serial, USB cable |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Package weight | 42.5 kg |
Logistics data | |
Harmonized System (HS) code | 8504408590 |
Certificates | |
Certification | CE , FCC Class B , UL , RCM , VCCI |
Other features | |
Bypass | GreenPower UPS |
Packaging content | |
Cables included | Serial, USB cable |
