Description
Network | |
---|---|
SFP transceiver type | Fiber optic |
Fiber optic connector | LC |
Networking standards | IEEE 802.3ae |
Maximum data transfer rate | 10000 Mbit/s |
Interface type | SFP+ |
Technical details | |
Package width | 74 mm |
Package height | 49 mm |
Maximum transfer distance | 300 m |
Wavelength | 850 nm |
Fiber cable diameters supported (core/cladding) | 50/125,62.5/125 µm |
Tx power (min) | -6.5 dBmW |
Tx power (max) | -1 dBmW |
Rx power (min) | -11.1 dBmW |
Rx power (max) | -1 dBmW |
Shipping (inner) case width | 26 cm |
Shipping (inner) case net weight | 3.2 kg |
Shipping (inner) case length | 36 cm |
Shipping (inner) case height | 31 cm |
Products per shipping (inner) case | 50 pc(s) |
Products per pallet (sea) | 3000 pc(s) |
Products per pallet (air) | 3000 pc(s) |
Pallet gross width | 122 cm |
Pallet gross length | 102 cm |
Pallet height (sea) | 199 cm |
Pallet height (air) | 199 cm |
Pallet gross weight (sea) | 272 kg |
Pallet gross weight (air) | 272 kg |
Master (outer) cases per pallet (sea) | 60 pc(s) |
Master (outer) cases per pallet (air) | 60 pc(s) |
Sustainability certificates | RoHS |
Performance | |
SFP transceiver type | Fiber optic |
Fiber optic connector | LC |
Networking standards | IEEE 802.3ae |
Maximum transfer distance | 300 m |
Wavelength | 850 nm |
Fiber cable diameters supported (core/cladding) | 50/125,62.5/125 µm |
Tx power (min) | -6.5 dBmW |
Tx power (max) | -1 dBmW |
Rx power (min) | -11.1 dBmW |
Rx power (max) | -1 dBmW |
Maximum data transfer rate | 10000 Mbit/s |
Interface type | SFP+ |
Multi-mode fiber (MMF) supported | Yes |
Harmonized System (HS) code | 85369010 |
Features | |
Certification | CE, FCC, VCCI, C-Tick |
Safety | UL, TUV, CDRH |
Power | |
Maximum voltage | 3.3 V |
Maximum current | 300 A |
Operational conditions | |
Operating temperature (T-T) | 0 - 70 °C |
Storage temperature (T-T) | -40 - 85 °C |
Operating relative humidity (H-H) | 5 - 85% |
Storage relative humidity (H-H) | 5 - 95% |
Weight & dimensions | |
Width | 14.8 mm |
Depth | 11.8 mm |
Height | 56.5 mm |
Weight | 18 g |
Package depth | 131 mm |
Package width | 74 mm |
Package height | 49 mm |
Package weight | 64 g |
Packaging data | |
Package depth | 131 mm |
Package width | 74 mm |
Package height | 49 mm |
Package weight | 64 g |
Certificates | |
Certification | CE, FCC, VCCI, C-Tick |
Safety | UL, TUV, CDRH |
Logistics data | |
Harmonized System (HS) code | 85369010 |
Shipping (inner) case width | 26 cm |
Shipping (inner) case net weight | 3.2 kg |
Shipping (inner) case length | 36 cm |
Shipping (inner) case height | 31 cm |
Products per shipping (inner) case | 50 pc(s) |
Products per pallet (sea) | 3000 pc(s) |
Products per pallet (air) | 3000 pc(s) |
Pallet gross width | 122 cm |
Pallet gross length | 102 cm |
Pallet height (sea) | 199 cm |
Pallet height (air) | 199 cm |
Pallet gross weight (sea) | 272 kg |
Pallet gross weight (air) | 272 kg |
Master (outer) cases per pallet (sea) | 60 pc(s) |
Master (outer) cases per pallet (air) | 60 pc(s) |
Shipping (inner) case gross weight | 4.2 kg |
