Epson SureColor SC-T7700D

SureColor SC-T7700D

Key Features

• Enhanced security features: Protect highly confidential documents with ease
• Compact and contemporary design: Fits seamlessly into most working environments
• Impressive print speeds: Up to 130m{s2/hr
• Versatility: Automatic media loading, dual roll, auto take-up, and auto-switching
• Quality: 6-colour printer with 350/700ml ink cartridges

Reasons To Buy

Legal Statement

Complies with The UK Product Security and Telecommunications Infrastructure (Product Security) requirements. Epson will provide security updates for 7 years from purchase

Description

44-inch technical printer
The SureColor SC-T7700D is a technical printer that's been designed for various applications, including: precise line definition, colour accuracy, and security for AEC/CAD/GIS plans and drawings; bright colour and high speed production for POS posters in retail; and precision, colour replication, and security for public sector printing.

Complete document solution
The SC-T7700D includes enhanced IT and security features. This is particularly useful for designers, architects and construction companies who print detailed plans and drawings, while protecting confidential documents. Collaboration is further improved, and workloads managed more efficiently, through central management tracking applications: Epson Cloud Solutions PORT and Epson Device Admin for IT managers.

Fast and feature-rich
High productive output speeds are achieved with the PrecisionCore MicroTFP printhead, Variable Sized Droplet Technology and Nozzle Verification Technology.

Compact footprint - versatile design
The SureColor SC-T7700D design is both contemporary and compact. It fits into most working environments because of its flat and unobtrusive design, which is space saving and practical.

Highly detailed prints, every time
Whether printing detailed architectural, engineering and construction (AEC) CAD prints, or POS posters for retail, the SureColorSC-T7700D's output is both precise and vibrant. The printer features an Epson PrecisionCore MicroTFP printhead and 6-colour UltraChrome XD3 all pigment inks, which include a new red ink to broaden the overall colour gamut.

Business solutions
The SureColor SC-T7700D is supported by industry-leading software providers for production enhancement and managed print systems.

Specifications

Print technology
Number of print cartridges	6
Print technology	Inkjet
Printing colours	Black, Cyan, Magenta, Matte black, Photo black, Red, Yellow
Colour	Yes
Print head nozzles	1.600 nozzles per colour
Colour management	ICC Profile
Maximum resolution	1200 x 2400 DPI
Page description languages	ESC/P-R, HP-GL/2, PDF 1.7, PostScript 3
Printing
Print speed (normal quality, A1)	120 pph
Number of print cartridges	6
Print technology	Inkjet
Printing colours	Black, Cyan, Magenta, Matte black, Photo black, Red, Yellow
Colour	Yes
Print head nozzles	1.600 nozzles per colour
Colour management	ICC Profile
Maximum resolution	1200 x 2400 DPI
Page description languages	ESC/P-R, HP-GL/2, PDF 1.7, PostScript 3
Copying
Copying	No
Scanning
Scanning	No
Print quality
Printing colours	Black, Cyan, Magenta, Matte black, Photo black, Red, Yellow
Minimum line width	0.02 mm
Maximum resolution	1200 x 2400 DPI
Print quality (black, draft quality)	600 DPI
Ink drop	3.5
Paper handling
Maximum roll width	111.8 cm
Borderless printing width	10" (25.4cm) Roll, 17" (43.1cm) Roll, 24" (60.9cm) Roll, 36" (91.4cm) Roll, 44" (111.8cm) Roll
Media thickness	SingleSheet0.1
ISO B-series sizes (B0...B9)	B0, B1
ISO A-series sizes (A0...A9)	A0, A2, A3, A4, A5
Maximum print size	A2 (420 x 594 mm)
Paper tray media types	Roll
Auto take-up reel	Yes
Media types
Paper tray media types	Roll
Media formats
Maximum roll width	111.8 cm
ISO B-series sizes (B0...B9)	B0, B1
ISO A-series sizes (A0...A9)	A0, A2, A3, A4, A5
Display
Touchscreen	Yes
Display	LCD
Ports & interfaces
USB port	Yes
Wi-Fi	Yes
Direct printing	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
USB 2.0 ports quantity	1
Ethernet LAN	Yes
Mobile printing technologies	Apple AirPrint
Technical details
Line accuracy	+/- 0,26
Direct printing	Yes
Quantity per pack	1 pc(s)
Performance
Product colour	Black, White
Internal memory	4096 MB
Display	LCD
Sound power level (standby)	6.6 dB
Sound pressure level (printing)	6.6 dB
Colour display	Yes
Control type	Touch
Built-in display	Yes
Display diagonal	10.9 cm (4.3")
Country of origin	Indonesia
Network
Wi-Fi	Yes
Direct printing	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Ethernet LAN	Yes
Memory
Internal memory	4096 MB
Design
Touchscreen	Yes
Product colour	Black, White
Display	LCD
Colour display	Yes
Control type	Touch
Built-in display	Yes
Display diagonal	10.9 cm (4.3")
Sound emission
Sound power level (standby)	6.6 dB
Sound pressure level (printing)	6.6 dB
Power
Power consumption (typical)	70 W
Power consumption (standby)	0.3 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
System requirements
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP
Weight & dimensions
Width	1848 mm
Depth	499 mm
Height	975 mm
Weight	155 kg
Packaging data
Cartridge(s) included	Yes
Manual	Yes
Colour
Colour management	ICC Profile
Packaging content
Cartridge(s) included	Yes
Manual	Yes
Features
Country of origin	Indonesia
Other features
Touchscreen	Yes
Line accuracy	+/- 0,26
Minimum line width	0.02 mm
Print quality (black, draft quality)	600 DPI
Ink drop	3.5
Logistics data
Quantity per pack	1 pc(s)
