HPE 5900CP-48XG-4QSFP+ Managed L3 Black

HP FlexFabric 5900CP-48XG-4QSFP+ Switch

Description

The HP FlexFabric 5900CP Switch Series provides a converged, top-of-rack, data center switch architecture that offers wire once for FCoE converged environments. With 48 converged ports that support 1/10GbE and 4/8 FC, the FlexFabric 5900CP delivers versatile convergence for connecting FC, iSCSI and FC SANs.

Resilience and ease of management come hand–in-hand with the FlexFabric 5900CP. While IRF reduces management complexities by up to 88%, it also delivers <50 msec convergence time.

You can rely on the FlexFabric 5900CP to lower TCO, while delivering business resilience and high availability.

Features
Wire Once Data Center Convergence with FCoE

The HP FlexFabric 5900CP Switch Series provides 48 converged ports supporting 1/10GbE and 4/8Gbps FC for increased flexibility of deployment.

All 48 ports support LAN, iSCSI, NAS, FC and FC SANs, so that you can support diverse storage choices.

Converged transceiver supporting 1/10GbE and 4/8/16Gbps FC allowing for future growth as well as backward compatibility.

High-Performance Data Center Switching

The HP FlexFabric 5900CP Switch Series delivers 1.28Tbps switching capacity for the most demanding applications.

Supports up to 952 MPPS throughput for data intensive environments.

Low latency, under a 1.5us 10GbE latency, provides business agility.

Four 40GbE QSFP+ ports for blazing fast uplinks.

Business Agility and Resilience with Comware 7

The HP FlexFabric 5900CP Switch Series delivers IRF <50msec convergence time enabling faster applications response time.

In Service Software Update (ISSU) enables high availability with updates accomplished without a reboot or power cycle, in the background.

Simplicity and Lower TCO

The HP FlexFabric 5900CP Switch Series simplifies switch management by up to 88% with IRF.

No extra hidden cost with simple one license per switch for all OS features.

All switch ports are active and ready to use without need for activation licenses.

Automate tedious tasks with SDN and reclaim wasted resources.

Specifications

Performance
Packet buffer memory	9 MB
Stackable	Yes
Internal memory	2048 MB
Flash memory	512 MB
Technical details
Product colour	Black
Stackable	Yes
Rack mounting	Yes
Management features
Switch type	Managed
Switch layer	L3
Ports & interfaces
SFP+ module slots quantity	48
QSFP+ module slots quantity	4
Data transmission
Throughput	952 Mpps
Packet buffer memory	9 MB
Switching capacity	1280 Gbit/s
Memory
Packet buffer memory	9 MB
Internal memory	2048 MB
Flash memory	512 MB
Design
Product colour	Black
Stackable	Yes
Rack mounting	Yes
Power
Power supply included	No
AC input frequency	50 - 60 Hz
Power over Ethernet (PoE)
Power over Ethernet (PoE)	No
Weight & dimensions
Width	439.9 mm
Depth	659.9 mm
Height	43.7 mm
Weight	13 kg
