HPE Aruba Networking 8325-48Y8C 48p 25G SFP/+/28 8p 100G QSFP+/28 FB 6 Fans 2 PSU Managed L3 1U Black

Aruba 8325-48Y8C 48p 25G SFP/+/28 8p 100G QSFP+/28 Front-to-Back 6 Fans & 2 PSU Bundle

Description

The Aruba 8325 switch serves as both a campus (core and aggregation) and data center (Top of Rack) switch. This game-changing solution offers an innovative approach to dealing with network demands in the mobile, cloud and IoT era. The Aruba 8325 is based on ArubaOS-CX, a modern software system that automates and simplifies critical and complex network tasks, delivers enhanced fault tolerance and facilitates zero-service disruption during planned or unplanned control-plane events. The key innovations in ArubaOS-CX are its microservices style modular architecture, REST APIs, Python scripting capabilities and the Aruba Network Analytics Engine. The Aruba 8325 Switch Series provides line rate 1GbE, 10GbE, 25GbE, and 40GbE in a compact 1U form factor.

What's new
- High-performance Aruba campus core and aggregation switch and data center top-of-rack switch with 6.4 Tbps switching capacity.
- ArubaOS-CX automates using REST APIs and Python scripts.
- Monitor and troubleshoot with Aruba Network Analytics Engine.
- High availability, virtualization and simplicity with redundant power supplies and fans and Aruba VSX.
- Compact 1U switches with 1GbE, 10GbE, 25GbE, 40GbE, and 100GbE connectivity.
- Advanced Layer 2/3 feature set includes BGP, OSPF, VRF, VXLAN, and IPv6.

Features

Game-changing Business Agility
- The Aruba 8325 Switch Series is a campus core and aggregation switch and data center Top of Rack solution with an innovative and powerful approach to dealing with the cross-domain demands of the mobile, cloud, and IoT era.
- Fully programmable with ArubaOS-CX, it brings automation and visibility and helps troubleshoot via simple scripting.
- Aruba Network Analytics Engine provides the ability to monitor and troubleshoot the network, system, application and security related issues easily, through simple python agents and REST APIs.
- Offers high-speed fully distributed architecture with 6.4Tbps of switching capacity.
- Provides robust security and QoS with advanced Layer 2 and Layer 3 features including support for BGP, OSPF, VRF and VXLAN.

Modern Software System Simplifies and Automates
- The Aruba 8325 Switch Series is based on the new ArubaOS-CX, a modern software system that automates and simplifies many critical and complex network tasks.
- The built-in time series database enables customers and developers to develop software modules for historical troubleshooting, as well as analysis of historical trends, to predict and avoid future problems due to scale, security, and performance bottlenecks.
- It includes stability, independent monitoring and restart of individual software modules, and enhanced software process serviceability functions. It also allows individual software modules to be upgraded for higher availability.

High Performance and High Availability
- The Aruba 8325 Switch Series includes a high-speed, fully distributed architecture and provides up to 6.4Tbps switching capacity to meet the demands and bandwidth-intensive applications today and in the future.
- Aruba’s high-availability technology is Aruba VSX which has been designed from ground up to deliver continuous availability, virtualization and simplicity requirements. Redundant and hot-swappable power supplies and fans provide additional resiliency.
- The compact 1U switch delivers line rate 1GbE, 10GbE, 25GbE, 40GbE, and 100GbE with very low latency. Optimize for your deployment with models that provide 48 ports of 1/10/25 GbE + 8 ports of 40/100GbE or 32 ports of 40/100GbE.

Specifications

Management features
Switch type	Managed
Quality of Service (QoS) support	Yes
Multicast support	Yes
Switch layer	L3
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	0
Basic switching RJ-45 Ethernet ports type	No
QSFP28 ports quantity	8
SFP28 ports quantity	48
Network
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3ba, IEEE 802.3x, IEEE 802.3z
VLAN support	Yes
Spanning tree protocol	Yes
Port mirroring	Yes
10G support	Yes
MLD entries	4094
IPv6 multicast entries	4094
IPv4 multicast entries	4094
Data transmission
Throughput	1905 Mpps
Packet buffer memory	32 MB
MAC address table	98304 entries
Supported data transfer rates	1/10/25/40/100 Gbps
Switching capacity	6400 Gbit/s
Jumbo frames support	Yes
Maximum data transfer rate	100 Gbit/s
Security
Access Control List (ACL)	Yes
Authentication type	RADIUS
DHCP features	DHCP server
Multicast features
Multicast support	Yes
MLD entries	4094
IPv6 multicast entries	4094
IPv4 multicast entries	4094
Design
Form factor	1U
Product colour	Black
Stackable	Yes
Rack mounting	Yes
Number of fans	6 fan(s)
Performance
Processor frequency	2200 MHz
Internal memory	16384 MB
Flash memory	8192 MB
Built-in processor	Yes
Packet buffer memory	32 MB
Stackable	Yes
Power
Power supply included	Yes
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	550 W
Redundant power supply (RPS) support	Yes
Number of power supply units	2
Power over Ethernet (PoE)
Power over Ethernet (PoE)	No
Operational conditions
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%
Virtual LAN features
VLAN support	Yes
Weight & dimensions
Width	438.5 mm
Depth	536 mm
Height	43.5 mm
Weight	10 kg
Technical details
Form factor	1U
Product colour	Black
Stackable	Yes
Processor frequency	2200 MHz
Rack mounting	Yes
Built-in processor	Yes
Memory
Packet buffer memory	32 MB
Internal memory	16384 MB
Flash memory	8192 MB
