HPE Aruba Networking AP-587 (EGF1) Dual Radio 4x4 Wi-Fi 6 Internal Directional TAA Outdoor AP

Aruba Networking AP-587 (EGF1) Dual Radio 4x4 Wi-Fi 6 Internal Directional TAA Outdoor AP

Reasons To Buy

High Performance Wi-Fi 6 APs Designed For Outdoors

HPE Aruba Networking 580 Series Outdoor Access Points are ideal for large scale outdoor environments including universities, large enterprises, and industrial applications and provide peak aggregate data rate of 2.97 Gbps.
The AP includes options for 5G Ethernet, SFP+, and PSE out for flexible connectivity.
It includes features such as OFDMA, bidirectional MU-MIMO, and target wait time (TWT) for better multi-user performance and improved efficiency.
It offers enhanced wireless experience with HPE Aruba Networking ClientMatch technology that removes sticky client issues by steering a client to the AP where it receives a strong radio signal.
Dual redundant power/port failover and support for AC provide high availability with uninterrupted performance.

Weatherproof and Temperature Hardened

HPE Aruba Networking 580 Series Outdoor Access Points can withstand extreme temperatures, persistent moisture and precipitation, and are fully sealed to keep out airborne contaminants.
Weatherproof and temperature hardened, this series can handle temperatures ranging from -40°C to +65°C, including full sun deployments.
The 580 series is IP66/67 rated with industrial surge protection.
The 580 series includes models with integrated, high-power antennas for increased performance and coverage, as well as a connectorized model that supports external antennas.

Industrial IoT Ready

HPE Aruba Networking 580 Series Outdoor Access Points can serve as IoT platforms that bolster network security and provide coverage for a range of IoT devices without the need for network overlays.
The 580 series provides high power Bluetooth and 802.15.4/Zigbee radios for increased IoT coverage.
The intelligent power monitoring (IPM) feature provides the ability to enable or disable capabilities based on available Power over Ethernet (PoE) power.
The target wake time (TWT) improves the battery life of IoT devices.
HPE Aruba Networking Central Client Insights uses deep packet inspection to provide additional context and behavioral information that help verify devices are receiving proper policy enforcement and continuously monitor for rogue devices.

Enhanced Security

The HPE Aruba Networking 580 Series Outdoor Access Points offer enhanced security with dynamic segmentation to remove the time consuming and error-prone task of managing complex and static VLANs, ACLs, and subnets by dynamically assigning policies and keeping traffic protected and separated.
It offers stronger encryption and authentication with WPA3, protected credentials/keys storage for guest access with Enhanced Open, and user and IoT access policy enforcement firewalls (PEFs).
The 580 series simplifies policy enforcement by using the PEF to encapsulate all traffic from the AP to the gateway (or mobility controller) for end-to-end encryption and inspection.
For enhanced device assurance, our APs include an installed trusted platform module (TPM) for protected storage of credentials, keys, and boot code.

Description

HPE Aruba Networking 580 Series Outdoor Access Points are our flagship Wi-Fi 6 outdoor APs purpose built to survive the harshest outdoor environments. With Wi-Fi 6 capabilities, high power Bluetooth and 802.15.4/Zigbee radios, and peak aggregate data rate of 2.97 Gbps, the 580 series delivers the speed and reliability needed for large enterprises and Industrial Internet of Things (IoT) deployments. These high-performance Wi-Fi 6 outdoor access points are IP66/67 rated to survive high wind, extreme temperatures, and moisture and can be quickly deployed using zero touch provisioning (ZTP). HPE Aruba Networking Central provides a single pane of glass for overseeing wired and wireless LANs, WANs, and VPNs. AI‑powered analytics, end‑to‑end orchestration and automation, and advanced security features are built natively into the solution. The 580 series outdoor APs include a limited lifetime warranty.

What is new supporting point:
Flexible connectivity and power options with support for 5 Gbps multi-gigabit Ethernet ports and 802.3bt Class 6 power or AC power
Purpose built to survive in the harshest outdoor environments and extreme temperatures (-40°C to +65°C) with IP66/67 ratings
Outdoor Wi-Fi 6 access points provide peak aggregate data rate of 2.97 Gbps
Client and RF optimization to match clients with the best available access point and reduce coverage gaps
Bluetooth and 802.15.4/Zigbee radios with high power to meet Industrial IoT requirements

Specifications

Data transmission
Ethernet LAN data rates	1000,5000 Mbit/s
Maximum data transfer rate	2970 Mbit/s
Performance
2.4 GHz	Yes
5 GHz	Yes
Spread spectrum method	DSSS, OFDM, OFDMA
Frequency band	20/40 (2.4 GHz), 20/40/80/(80+80) (5 GHz), peak data rate 2.97 Gbps, maximum data rate 3.55 Gbps
Number of users	1024 user(s)
Networking standards	IEEE 802.11ax, IEEE 802.11mc
Ethernet LAN data rates	1000,5000 Mbit/s
Certification	Wi-Fi Alliance Bluetooth SIG Ethernet Alliance (E0, PoE PD device, class 6; E2, PoE PSE device, class 3)
Maximum data transfer rate	2970 Mbit/s
MIMO type	Single User MIMO
MIMO	Yes
Compatible operating systems	HPE Aruba Networking Wireless Operating System 8 and HPE Aruba Networking Instant OS 8 HPE Aruba Networking Operating System OS10
Wireless LAN features
Frequency band	20/40 (2.4 GHz), 20/40/80/(80+80) (5 GHz), peak data rate 2.97 Gbps, maximum data rate 3.55 Gbps
Network
Spread spectrum method	DSSS, OFDM, OFDMA
Number of users	1024 user(s)
Networking standards	IEEE 802.11ax, IEEE 802.11mc
Ports & interfaces
I/O ports	Ethernet wired port (RJ-45) Ethernet wired port (RJ-45) PSE Ethernet wired port (SFP+) USB-C console interface
USB connector type	USB Type-C
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Features
6 GHz	No
2.4 GHz	Yes
5 GHz	Yes
Spread spectrum method	DSSS, OFDM, OFDMA
Frequency band	20/40 (2.4 GHz), 20/40/80/(80+80) (5 GHz), peak data rate 2.97 Gbps, maximum data rate 3.55 Gbps
Number of users	1024 user(s)
Networking standards	IEEE 802.11ax, IEEE 802.11mc
Ethernet LAN data rates	1000,5000 Mbit/s
Maximum data transfer rate	2970 Mbit/s
Bluetooth	Yes
Bluetooth version	5.0
MIMO type	Single User MIMO
MIMO	Yes
Trusted Platform Module (TPM)	Yes
MACsec support	No
Compatible operating systems	HPE Aruba Networking Wireless Operating System 8 and HPE Aruba Networking Instant OS 8 HPE Aruba Networking Operating System OS10
Security
Security algorithms	WPA2, WPA3
Management features
Access point management	On-premises; Public Cloud; Virtual Private Cloud (VPC); as a Service
Power
Power consumption (typical)	71 W
Power over Ethernet (PoE)	Yes
Design
International Protection (IP) code	IP66, IP67
Placement	Ceiling, Pole, Wall
Product colour	White
Certification	Wi-Fi Alliance Bluetooth SIG Ethernet Alliance (E0, PoE PD device, class 6; E2, PoE PSE device, class 3)
Recommended usage	Outdoor
Antenna
Antenna type	Internal
Antennas quantity	4
Antenna gain level (max)	6.6 dBi
Antenna direction type	Directional
Antenna features	Integrated antenna
Technical details
Weight (imperial)	4.51 kg (9.94 lbs)
Compliance certificates	Federal Communications Commission (FCC), ISED, CE, Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD)
Certificates
Certification	Wi-Fi Alliance Bluetooth SIG Ethernet Alliance (E0, PoE PD device, class 6; E2, PoE PSE device, class 3)
Compliance certificates	Federal Communications Commission (FCC), ISED, CE, Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD)
Weight & dimensions
Width	302 mm
Depth	300 mm
Weight	4.51 kg
Height	174 mm
Package width	385 mm
Package depth	272 mm
Package height	433 mm
Package weight	6.03 kg
Packaging data
Package width	385 mm
Package depth	272 mm
Package height	433 mm
Package weight	6.03 kg
Other features
I/O ports	Ethernet wired port (RJ-45) Ethernet wired port (RJ-45) PSE Ethernet wired port (SFP+) USB-C console interface
Weight (imperial)	4.51 kg (9.94 lbs)
Operational conditions
Operating relative humidity (H-H)	5 - 93%
Operating temperature (T-T)	-40 - 65 °C
Storage temperature (T-T)	-40 - 70 °C
Operating altitude	0 - 3000 m
System requirements
Compatible operating systems	HPE Aruba Networking Wireless Operating System 8 and HPE Aruba Networking Instant OS 8 HPE Aruba Networking Operating System OS10
