HPE MSA 2062 disk array 3.84 TB Rack (2U)

MSA 2062 10GbE iSCSI SFF Storage

Description

Looking for seriously simple and affordable flash storage?

The HPE MSA 2062 Storage is a flash-enabled system designed for affordable application acceleration for small and remote office deployments. Don’t let the low cost fool you. The HPE MSA 2062 gives you the combination of simplicity, flexibility and advanced features you many not expect in an entry-priced storage array. Starting with 3.84 TB of embedded flash capacity, you can scale the system from there with any combination of solid state disks (SSD), high-performance Enterprise SAS HDDs, or lower-cost Midline SAS HDDs. Capable of delivering in excess of 325,000 IOPS, the HPE MSA 2062 saves you up to 32% with an all-inclusive software suite and 3.84 TB of flash capacity included. It’s seriously simple and affordable flash storage to help you achieve high performance yet meet challenging budgets.

Features

Affordable Application Acceleration
- The HPE MSA 2062 Storage is capable of delivering over 325,000 IOPS for affordable application acceleration for small to medium-sized businesses.
- Save 32% on HPE MSA 2062 with all-inclusive software and 3.84 TB of Solid State Drive (SSD) capacity included.

MSA’s 'set and forget' Data Services does not Require a Dedicated Storage Administrator to Manage
- The HPE MSA 2060 Storage is easy to install, easy to use, easy to maintain, even for an IT generalist. Administrators will find the MSA 2060’s new Storage Management Utility intuitive and easy to navigate.
- MSA’s automated tiering engine dynamically responds to workload changes so you don’t have to, insuring the hottest data will be moved to the fastest media automatically and in real-time.

Leverage Data Protection Features to Keep your Business Running in the Event of a Disaster
- The HPE MSA 2060 Storage delivers virtualized snapshot technology making data protection and instant recovery a snap.
- Remote replication via Fibre Channel (FC) or iSCSI facilitates affordable disaster recovery solution.
- Encrypted SSDs and HDDs with local key management can be deployed to deliver a secure, encrypted hybrid flash array.

Flexible, Modular Architecture that Facilitates Growth into the Future
- The HPE MSA 2060 Storage supports a mixture of 3.5 inch LFF and 2.5 inch SFF expansion enclosures for a maximum of 9 (10 including base system) enclosures.
- Start small and scale as needed with any combination of SSDs, Enterprise SAS or MidLine SAS HDDs.

Specifications

Storage
Total installed storage capacity	3.84 TB
Installed storage drive type	SSD
Number of storage drives installed	2
Supported storage drive types	HDD & SSD
Number of storage drives supported	24
Storage drive capacity	1.92 TB
Storage drive size	2.5"
Storage drives installed	Yes
Maximum supported storage capacity	921 TB
RAID levels	0, 1, 5, 6, 10
Data transfer rate	10 Gbit/s
Ports & interfaces
USB connectivity	No
Host ports	8
Technical details
Device class	Small & Medium Business
Chassis type	Rack (2U)
Storage mirroring	Yes
SAN backup support	Yes
Data transfer rate	10 Gbit/s
Harmonized System (HS) code	84717020
Design
Chassis type	Rack (2U)
Performance
Device class	Small & Medium Business
Maximum number of controllers supported	2
Hard drive
RAID levels	0, 1, 5, 6, 10
Power
Number of power supply units	2
AC input voltage	100 - 230 V
AC input frequency	50 - 60 Hz
Redundant power supply (RPS) support	Yes
System requirements
Other operating systems supported	Yes
Server operating systems supported	Windows Server 2016, Windows Server 2019
Linux operating systems supported	Yes
Weight & dimensions
Width	445 mm
Depth	508 mm
Weight	5 kg
Height	89 mm
Logistics data
Harmonized System (HS) code	84717020
Other features
Controller interface type	iSCSI
Storage mirroring	Yes
SAN backup support	Yes
