HPE ProLiant DL80 G9 server 0 GB Rack (2U) Intel Xeon E5 v3 E5-2609V3 1.9 GHz 8 GB DDR4-SDRAM 550 W

ProLiant DL80 Gen9 E5-2609v3 1.9GHz 6-core 8GB-R H240 8LFF 550W PS Entry Server

Description

Do you need an affordable storage server for capacity intensive applications? The HP ProLiant DL80 Gen9 Server is designed with affordable storage, networking and processor scalability, and manageability in a 2U server for cost conscious service provider and SMBs. Apart from basic IT infrastructure workloads this server is ideal for running storage capacity intensive applications like cold storage, back-up due to compelling cost/GB that it offers.

Affordable Storage and IO Expandability for Service Providers and SMBs
The HP ProLiant DL80 Gen9 Server provides ample storage capacity with up to twelve (12) Large Form Factor (LFF) HP SmartDrives, delivering optimal performance, capacity, and reliability to meet various customer segments and workload requirements at the right economics.
Up to six (6) PCIe 3.0 riser slots to support one single-wide GPU or networking cards offering increased IO bandwidth and seamless expandability.
Comes standard with 2x1GbE and choice of HP FlexibleLOM to provide you flexibility of networking bandwidth and fabric so you can adapt to changing business needs.

Just Enough Performance for Basic IT Infrastructure Workloads
The HP ProLiant DL80 Gen9 Server supports up to two (2) Intel® Xeon® processor E5-2600 v3 processors offering improved performance and efficiency.
HP SmartMemory has the built-in intelligence to improve performance, reduce downtime and energy costs resulting in up to 14% 1 better throughput performance and up to 37% lower power consumption with DDR4 memory.
Embedded SATA HP Dynamic Smart Array B140i Controller for boot and data. Choice of HP Smart Array Controllers with increased performance, data availability with 12 Gb/s SAS technology or HP Smart HBAs with reliable high performance SAS connectivity capable of running HBA mode or simple RAID mode.

Agile Infrastructure Management for Accelerating IT Service Delivery
With HP ProLiant DL80 Gen9 Server, HP OneView provides converged management for automation simplicity across servers, storage and networking.
Online personalized dashboard for converged infrastructure health monitoring and support management with HP Insight Online.
Configure in Unified Extensible Firmware Interface (UEFI) boot mode, provision local and remote with Intelligent Provisioning and Scripting Toolkits or HP RESTful Interface Tool.
Embedded management to deploy, monitor and support your server remotely, out of band with HP iLO.
Optimize firmware and driver updates and reduce downtime with HP Smart Update, consisting of HP SUM and SPP.

Energy Efficiency by Design
80 PLUS gold certified entry-level redundant HP Power Supplies provide up to 92% efficiency which combined with HP power management features leads to reduction of power consumption and expense.
Improved ambient temperature standard with ASHRAE A3 2 helps customers reduce cooling expense.

Specifications

Processor
Thermal Monitoring Technologies	Yes
Thermal Design Power (TDP)	85 W
Tcase	70.9 °C
Supported instruction sets	AVX 2.0
Stepping	M1
Scalability	2S
Processor threads	6
Processor package size	52.5 x 45 mm
Processor operating modes	64-bit
Processor lithography	22 nm
Processor codename	Haswell
Physical Address Extension (PAE)	46 bit
Physical Address Extension (PAE)	Yes
PCI Express configurations	x4, x8, x16
Number of QPI links	2
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	1600,1866,2133 MHz
Memory channels supported by processor	Quad
Memory bandwidth supported by processor (max)	51 GB/s
Maximum number of PCI Express lanes	40
Maximum internal memory supported by processor	768 GB
Idle States	Yes
FSB Parity	No
Execute Disable Bit	Yes
Embedded options available	Yes
ECC supported by processor	Yes
Bus type	QPI
Processor cache type	Smart Cache
Processor cache	15 MB
Conflict-Free processor	No
Processor series	Intel Xeon E5-2600 v3
Processor frequency	1.9 GHz
Number of processors installed	1
Processor model	E5-2609V3
System bus rate	6.4 GT/s
Processor socket	LGA 2011-v3
Processor cores	6
Processor manufacturer	Intel
Motherboard chipset	Intel C610
Processor family	Intel Xeon E5 v3
Memory
Internal memory	8 GB
Memory layout (slots x size)	1 x 8 GB
Memory slots	8x DIMM
Memory clock speed	2133 MHz
Maximum internal memory	128 GB
Internal memory type	DDR4-SDRAM
Storage
Total storage capacity	0 GB
Number of HDDs installed	0
Optical drive type	No
Graphics
Thermal Design Power (TDP)	85 W
Graphics card family	Matrox
Graphics card	G200eH2
Network
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
VGA (D-Sub) ports quantity	1
USB 2.0 ports quantity	1
Serial ports quantity	0
Ethernet LAN (RJ-45) ports	2
Expansion slots
PCI Express slots version	3.0
Optical drive
Optical drive type	No
Design
Redundant fans support	Yes
Optical drive type	No
Chassis type	Rack (2U)
Performance
Operating system installed	No
Software
Operating system installed	No
Processor special features
Intel® Wireless Display (Intel® WiDi)	No
Intel® Identity Protection Technology (Intel® IPT)	No
Enhanced Intel SpeedStep Technology	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® OS Guard	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel® Turbo Boost Technology	No
Intel TSX-NI	No
Intel Trusted Execution Technology	Yes
Intel® Smart Cache	Yes
Intel® Secure Key	Yes
Intel® Quick Sync Video Technology	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel Flex Memory Access	No
Intel Enhanced Halt State	Yes
Intel Demand Based Switching	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel Clear Video Technology	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel 64	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel TSX-NI version	0.00
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Intel FDI Technology	No
Intel Dual Display Capable Technology	No
Intel Fast Memory Access	No
Processor ARK ID	81897
Intel Rapid Storage Technology	No
CPU configuration (max)	2
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Power
Number of main power supplies	1
Power supply	550 W
Technical details
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Intel Rapid Storage Technology	No
Redundant fans support	Yes
Ethernet interface type	Gigabit Ethernet
CPU configuration (max)	2
Chassis type	Rack (2U)
Weight & dimensions
Width	434.7 mm
Weight	27 kg
Height	87.6 mm
Depth	634.3 mm
Other features
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Graphics card family	Matrox
Graphics card	G200eH2
CPU configuration (max)	2
