Kensington K:MltUser Dck LD4650P USB-C KF

K:MltUser Dck LD4650P USB-C KF

Key Features

• Best for: USB-C Laptops & Ultrabooks that support Power Delivery and Monitors that support up to 1080p
• Connection technology: USB-C Alt Mode
• USB-C power delivery: Supports USB-C PD 3.0 (60W of laptop charging)
• Compatibility: Windows 10
• No. of monitors supported: 2
• Maximum resolution supported: Single monitor (2560 x 1440 @ 60Hz) and Dual monitors (1920 x 1080 @ 60Hz)

Reasons To Buy

IT controlled access

Provides IT administrators with the benefit of master access to all stations, including those used for hot-desking, hoteling and/or shared workspaces. Also available with Single-User access (K38400EU) for a simple locking experience for fixed desk users.

Flexible security options

The station can be secured to any fixed object using the removable tethered lock cable, or by using the built-in Kensington Security Slot with a cable lock, or permanently secured to a desktop using the pre-drilled mounting holes.

Register & Retrieve™

The industry-leading Register & Retrieve™ Lock Management Portal is a smart cloud-based platform for the management of all Kensington locks. Providing IT managers and users with individual accounts and on-demand access to support services, the simple key registration process helps ensure records stay up to date following personnel changes and offers free key replacements.

Plug & Play

Provides a seamless docking station experience for supported Windows 10 systems.

USB-C connectivity

Transfer data (up to 10Gbps), video and audio while providing up to 60W of power delivery* to USB-C enabled laptops for a simple plug and play experience. *Supported USB-C devices with PD function only

Dual 1080P video outputs**

Two DisplayPort++ ports enable video output connections to external monitors, TVs or projectors for Windows users. **Host device must support Alt mode over USB-C; only for Windows

Productivity ports

Connect to peripheral accessories via two USB-A 3.2 Gen 2 ports (10Gbps;5V/0.9A), two USB-A 3.2 Gen 1 ports (5Gbps;5V/0.9A), one 1Gbps Ethernet port and a combo 3.5mm audio in/out port.

K-Fob™ Smart Lock technology

Combining encrypted security with the simplicity of keyless locking, Kensington’s K-Fob is the next generation of keying.

Professional locking design

Conforms to Kensington’s industry-leading testing standards for durability, reliability and tamper-resistance. Designed to provide unobstructed access to the laptop’s side ports so security doesn’t interfere with productivity. Does not require any laptop modifications.

Adjustable security arms

No tools are needed to easily adjust the station to fit 11”–15” thin and light laptops.

Scratch-resistant bumpers

The laptop rests on cushioned bumpers along the back and base to protect it from cosmetic damage.

Description

Best for: USB-C Laptops & Ultrabooks that support Power Delivery and Monitors that support up to 1080p
Warranty: 3 Years
Apple M1 - While this docking station will work with the M1 MacBook, only a single video output is supported. For multi-monitor support on your M1 MacBook, see our Hybrid USB-C DisplayLink docking stations (e.g.: SD4700P, SD4750P, SD4780P or SD4900P) or USB-A DisplayLink adapters (DisplayPort K33989, HDMI K33988, DVI-I K33974).
Connection technology: USB-C Alt Mode
USB-C power delivery: Supports USB-C PD 3.0 (60W of laptop charging)
Compatibility: Windows 10
No. of monitors supported: 2
Video output: 2 x DisplayPort++
Maximum resolution supported: Single monitor (2560 x 1440 @ 60Hz) and Dual monitors (1920 x 1080 @ 60Hz)
Plug & play installation without need for drivers or downloads
System requirements: Host device must support Power Delivery and DisplayPort Alt mode over USB-C

Specifications

Ports & interfaces
Combo headphone/mic port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Host interface	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Ethernet LAN (RJ-45) ports	1
DisplayPorts quantity	1
Microphone in	Yes
Headphone outputs	1
Connectivity technology	Wired
USB Power Delivery (USB PD)	No
USB Power Delivery revision	3.0
USB Power Delivery up to	60 W
Network
Ethernet LAN	Yes
Ethernet LAN data rates	1000,10,100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Performance
Maximum digital resolution	2560 x 1440 pixels
Number of displays supported	2
Country of origin	China
Product colour	Black, Silver
Card reader integrated	No
Cable lock slot	Yes
Plug and Play	Yes
LED indicators	Yes
Data transfer rate	10 Gbit/s
Certification	CE, FCC, IC, RCM, WEEE, REACH & IMDA
Cable lock slot type	Kensington
HD type	Full HD
Technical details
Product colour	Black, Silver
Cable lock slot	Yes
Plug and Play	Yes
Data transfer rate	10 Gbit/s
Compliance certificates	RoHS
Storage
Card reader integrated	No
Power
Input current	1.5 A
AC input voltage	100-240 V
AC input frequency	50-60 Hz
Output voltage	5 - 20 V
Output current	3 A
Software
Windows operating systems supported	Yes
Indication
LED indicators	Yes
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95%
Weight & dimensions
Weight	1.47 kg
Width	320 mm
Depth	220 mm
Height	44 mm
Package weight	3.34 kg
Package width	362 mm
Package depth	320 mm
Package height	83 mm
Design
Windows operating systems supported	Yes
Country of origin	China
Product colour	Black, Silver
Cable lock slot	Yes
LED indicators	Yes
Certification	CE, FCC, IC, RCM, WEEE, REACH & IMDA
Cable lock slot type	Kensington
Packaging data
Package weight	3.34 kg
Package width	362 mm
Package depth	320 mm
Package height	83 mm
Packaging content
Cables included	USB
Certificates
Certification	CE, FCC, IC, RCM, WEEE, REACH & IMDA
Other features
USB ports quantity	4
Compatible operating systems	Windows 10
