Kensington SD4843P EQ USB-C 10Gbps Triple Video Driverless Dock

SD4843P EQ USB-C 10Gbps Triple Video Driverless Dock

Key Features

• Supports up to three external monitors via 1 x HDMI® and 2 x DisplayPort™ (DP) connections.* * For maximum resolution, the DSC-enabled laptop, docking station, monitor and laptop all need to support DSC v1.2.
• Plug-and-play for Thunderbolt™ 5, Thunderbolt™ 4, USB4® and USB-C® Alt-Mode laptops running Windows 10 or Windows 11.
• Supports up to 100W of dynamic power delivery to host laptop and connected accessories.
• All five high-speed USB ports receive power and continue to charge even when the host laptop is undocked.
• 10-in-1 design offers a full suite of ports to seamlessly connect your peripherals.
• The outer case of this docking station is made of plastic containing 71% post-consumer recycled (PCR) content* and it is shipped in FSC® certified packaging.
• Security Cable Lock Slots
• Free Kensington DockWorks™ software.
• 3-year limited warranty.

Reasons To Buy

Triple Video Displays

Supports up to three external monitors via 1 x HDMI® and 2 x DisplayPort™ (DP) connections – delivering up to Triple 4K @ 30Hz* or up to Single 8K @ 30Hz*. *For maximum resolution, the DSC-enabled laptop, docking station, monitor, and laptop all need to support DSC v1.2.

No Drivers or Downloads

Supports Thunderbolt™ 5, Thunderbolt™ 4, USB4®, and USB-C® Alt-Mode laptops running Windows 10 or Windows 11. A convenient plug-and-play dock that does not require drivers or downloads.

Up to 100W Dynamic Power Delivery

Delivers power whenever and wherever you need it - to host and connected accessories even when the laptop is not docked. Supports up to 100W of power delivery to USB-C® Alt Mode laptops and provides optimal performance under any usage scenario.

USB Ports with KonstantCharge™

All five high-speed USB ports feature KonstantCharge™ technology, ensuring that connected devices receive power and continue to charge even when the host laptop is undocked.

10-in-1 Design

Provides 1 x HDMI®2.1 video port, 2 x DP1.4 video ports, 5 x USB 3.2 Gen2 10Gbps ports, 1 x combo audio jack and 1 x Gigabit Ethernet port.* *This dock supports the Gigabit Ethernet standard which provides a maximum data rate of 1Gbps. Actual Ethernet speeds may vary depending on, but not limited to, Internet bandwidth, Ethernet cables, network switches, and the hardware and firmware performance of the host computer.

Sustainability Attributes

Outer case made of plastic containing 71% post-consumer recycled (PCR) content and delivered in Forest Stewardship Council (FSC®) certified packaging.

Security Cable Lock Slots

Protect your investment with a Kensington cable lock (K65020EU or K60603WW), sold separately.

Free Kensington DockWorks™ Software

Free DockWorks™ software for Windows users delivers the best connection, performance and security from your Kensington dock.

3-Year Limited Warranty

Enjoy peace of mind knowing you’re covered by Kensington with a professional warranty.

Description

The SD4843P EQ USB-C® 10Gbps Triple Video Driverless Dock is a versatile docking station supporting Thunderbolt™ 5, Thunderbolt™ 4, USB4® and USB-C® Alt Mode laptops with up to three external monitors. 1 x HDMI® and 2 x DisplayPort™ (DP) ports support up to Triple 4K @ 30Hz* or up to Single 8K @ 30Hz*. SD4843P provides up to 100W Dynamic Power Delivery and includes KonstantCharge™, delivering power to connected accessories even when the host laptop is undocked. The 10-in-1 design features five high-speed USB 3.2 Gen2 10Gbps ports (4 x USB-A and 1 x USB-C®), three video ports, a combo audio jack and a Gigabit Ethernet port**. The dock incorporates partially recycled materials and includes lock slots, free Kensington DockWorks™ software and a 3-year limited warranty.
* For maximum resolution, the DSC-enabled laptop, docking station, monitor and laptop all need to support DSC v1.2 (Display Stream Compression).
** This dock supports the Gigabit Ethernet standard which provides a maximum data rate of 1Gbps. Actual Ethernet speeds may vary depending on, but not limited to, Internet bandwidth, Ethernet cables, network switches and the hardware and firmware performance of the host computer.

Specifications

Ports & interfaces
Combo headphone/mic port	Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
USB Power Delivery (USB PD)	Yes
USB Power Delivery revision	3.0
USB Power Delivery up to	100 W
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Performance
Number of displays supported	3
Card reader integrated	No
Plug and Play	Yes
Data transfer rate	10 Gbit/s
HD type	4K Ultra HD
Technical details
Plug and Play	Yes
Data transfer rate	10 Gbit/s
Products per master (outer) case	6 pc(s)
Master (outer) case width	280 mm
Master (outer) case gross weight	9 kg
Master (outer) case length	485 mm
Master (outer) case height	190 mm
Storage
Card reader integrated	No
Software
Windows operating systems supported	Yes
Design
Windows operating systems supported	Yes
Packaging data
Quantity per pack	1 pc(s)
Package weight	1.4 kg
Package width	145 mm
Package depth	235 mm
Package height	87 mm
Weight & dimensions
Package weight	1.4 kg
Package width	145 mm
Package depth	235 mm
Package height	87 mm
Packaging content
Quantity per pack	1 pc(s)
Logistics data
Products per master (outer) case	6 pc(s)
Master (outer) case width	280 mm
Master (outer) case gross weight	9 kg
Master (outer) case length	485 mm
Master (outer) case height	190 mm
Master (outer) case net weight	9 kg
Other features
USB ports quantity	5
Compatible operating systems	Windows 10 or above
