Lenovo | SKU:
4Y37A78837
Lenovo 4Y37A78837 interface cards/adapter Internal Mini-SAS
€572.77
Unit price
/
Unavailable
Shipping calculated at checkout.
Lenovo 4Y37A78837 interface cards/adapter Internal Mini-SAS is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Delivery and Shipping
Delivery and Shipping
Products shipped within 2 working days from date of order.
Costs
0-24.99kg €14.50
25kg – 50kg €35.00
50kg and Up €60.00
No Customs Charges
No Customs Charges
Deliveries from Ireland & EU meaning no unwanted customs charges. No hidden charges.
ThinkSystem 440-8e SAS/SATA PCIe Gen4 12Gb HBA
Description
The Lenovo ThinkSystem 440-8e and 440-16e SAS/SATA 12Gb HBAs are high performance PCIe 4.0 host bus adapters for external storage connectivity in ThinkSystem servers. The adapters provide either two or four x4 external mini-SAS HD connectors to provide connectivity to external storage devices such as ThinkSystem DE Series storage and LTO9 tape drives. This product guide provides essential presales information to understand the ThinkSystem external HBAs and their key features, specifications, and compatibility. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the HBAs and consider their use in IT solutions.Specifications
| Ports & interfaces | |
|---|---|
| Internal | Yes |
| Output interface | Mini-SAS |
| Host interface | PCIe |
| Expansion card form factor | Low-profile |
| Expansion card standard | PCIe 4.0 |
| Host interface gender | Male |
| Technical details | |
| Purpose | Server |
| Data transfer rate (max) | 12 Gbit/s |
| Quantity per pack | 1 pc(s) |
| Performance | |
| Purpose | Server |
| Data transfer rate (max) | 12 Gbit/s |
| Product colour | Multicolour |
| S.M.A.R.T. support | Yes |
| Certificates | |
| Certification | FCC Part 15 Class A Australia/New Zealand (AS/NZS CISPR 22) Canada (ICES-003 Class B) Europe (EN55022/EN55024) Japan (VCCI V-3) Korea (RRA no 2013-24 & 25) RoHS compliant EN/IEC/UL 60950 Taiwan (CNS 13438) USA (FCC 47 CFR part 15 Subpart B class B) WEEE |
| Colour | |
| Product colour | Multicolour |
| Design | |
| Purpose | Server |
| Internal | Yes |
| Product colour | Multicolour |
| Certification | FCC Part 15 Class A Australia/New Zealand (AS/NZS CISPR 22) Canada (ICES-003 Class B) Europe (EN55022/EN55024) Japan (VCCI V-3) Korea (RRA no 2013-24 & 25) RoHS compliant EN/IEC/UL 60950 Taiwan (CNS 13438) USA (FCC 47 CFR part 15 Subpart B class B) WEEE |
| Features | |
| Data transfer rate (max) | 12 Gbit/s |
| S.M.A.R.T. support | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 10 - 55 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| System requirements | |
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
