Lindy 2m Cat.6A S/FTP Locking Network Cable, Grey

2m Cat.6A S/FTP LSZH Network Security Cable, Grey

Key Features

• Twisted Pair Patch Cable with RJ45 connectors
• Cat.6A S/FTP PIMF, LSZH
• Locking connectors to prevent unauthorized access only accessible with the included key
• Gold plated pins for better conductivity and elimination of signal loss

Description

Cat.6A S/FTP network cable with support for bandwidth up to 500MHz and features a snagless design with gold plated contacts for ethernet standards up to 10 GBase-T.
The Lindy Cat.6A Security Network Cable is a simple yet highly effective way of preventing accidental or malicious removal of cables on your network. Fully tamper resistant, Security key locks in the plug for added physical security allowing for removal only with the supplied key.
Cat.6A cable, shielded with braid as overall shield and foil shield for the individual wire pairs (S/FTP). Cat.6A cables meet the requirements of 10 Gigabit Ethernet (10GBaseT) with an operating frequency of up to 500MHz. These cables are manufactured and tested according to the ISO/IEC 11801 specification. The cables are packaged individually in a polybag.
The gold-plated contacts ensure reliable, corrosion-free connections over extensive periods of time. A robust snagless strain relief design prevents damage to the connector latch during installation and removal.
The halogen-free sheath material of the LSZH cable makes the product suitable for use in public spaces with its low smoke emission and elimination of toxic halogen emissions.
Available lengths: 0.3m, 0.5m, 1m, 1.5m, 2m, 3m, 5m, 7.5m, 10m, 15m, 20m

Specifications

Features
Product colour	Grey
Connector shielding	Yes
Connector shield material	Aluminium
Conductor material	Copper
Frequency	500 MHz
AWG wire size	26
Cable standard	Cat6a
Cable shielding	S/FTP (S-STP)
Connector 1	RJ-45
Connector 2	RJ-45
Connector contacts plating	Nickel/Gold
Jacket material	Low smoke zero halogen (LSZH)
Cable length	2 m
Connector 2 gender	Male
Connector 1 gender	Male
Bend radius (min)	7.2 cm
Nominal attenuation	49.3dB/100m @ 500MHz
Connector 2 form factor	Straight
Connector 1 form factor	Straight
Certification	RoHS, REACH
Operational conditions
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	-10 - 60 °C
Certificates
Certification	RoHS, REACH
Weight & dimensions
Outer diameter	6 mm
Connector 2 dimensions (WxDxH)	11.6 x 21.5 x 8.3 mm
Connector 1 dimensions (WxDxH)	11.6 x 21.5 x 8.3 mm
Packaging data
Package type	Polybag
Technical details
Product colour	Grey
Cable standard	Cat6a
Cable shielding	S/FTP (S-STP)
Connector 1	RJ-45
Connector 2	RJ-45
Connector contacts plating	Nickel/Gold
Jacket material	Low smoke zero halogen (LSZH)
Cable length	2 m
Other features
Package type	Polybag
