Multibrackets M Universal Wallmount Outdoor Tilt 600 MAX

Multibrackets M Universal Wallmount Outdoor 600 MAX - Wall mount for LCD / LED panel - black - screen size: 40"- 75" - max load: 50 kg - VESA: 200x200 - 600x400 mm - black - Dacrotized® ceramic

Key Features

• Made for indoor/outdoor usage with Dacrotized® corrosion resistant coating
• For screens up to 75" or 50kg
• Engineered to create a "free floating" impression
• Tilt your TV for perfect viewing for your outdoor installation
• Adjust the Display without tools
• Lateral shift for a perfect TV positioning slide TV from side to side
• Straps with smart magnets making access easy to the vertical arms when mounting/ dismounting

Description

This Outdoor Universal Tilt Wall Mount provides a sure way to mount flat panel displays outdoors with its corrosion resistant coating and stainless steel hardware details. In addition to simple installation with its hook and lock design, this mount offers tilt functionality while keeping the display a mere 35mm from the wall. Tamper resistant hardware deters theft, for additional security, the mount has accommodations for optional padlocks.

The M Universal Wallmount Outdoor 600 MAX tilting mounts gives you the best view. With its very unique design it is both strong and powerful, yet keeps your flat panel TV installed with minimal metal parts attached to the wall behind the TV creating a minimalistic look and feel. With built in lateral left and right adjustment possibilities it can be after adjusted.

Smart magnetic wires makes the lock and unlock procedure from the rail simple and easy.

Fingertip tilt allows for easy TV adjustments, without tools. The mount tilts your TV for easy cable access or to reduce glare. When installed the TV can slide from side-to-side for perfect positioning on the wall. Easy release your TV via safety straps well hidden behind the TV with smart magnets.

Specifications

Mounting
Mounting type	Wall
Minimum screen size	101.6 cm (40")
Panel mounting interface	200 x 200,300 x 300,300 x 200,400 x 200,400 x 400,400 x 300,600 x 400
Number of displays supported	1
Minimum VESA mount	200 x 200 mm
Maximum VESA mount	600 x 400 mm
Maximum screen size	190.5 cm (75")
Maximum weight capacity	50 kg
Ergonomics
Tilt angle range	0 - 12°
Distance to the wall (max)	3.3 cm
Tilt adjustment	Yes
Technical details
Number of displays supported	1
Distance to the wall (max)	3.3 cm
Product colour	Black
Mounting type	Wall
Plastic packaging weight	60 g
Metal packaging weight	2.94 kg
Paper/cardboard packaging weight	1 kg
Design
Product colour	Black
Weight & dimensions
Width	704 mm
Height	158 mm
Weight	3.4 kg
Depth (max)	7.4 cm
Packaging data
Package width	160 mm
Package depth	710 mm
Package height	800 mm
Package type	Box
Package weight	4 kg
Logistics data
Shipping (inner) case gross weight	24 kg
Products per shipping (inner) case	6 pc(s)
Other features
Mounting type	Wall
