SanDisk G-RAID SHUTTLE 4 disk array 48 TB Desktop Black

48 TB, 7200 RPM, 1000 MB/s read, 1100 MB/s write, Thunderbolt 3, USB 3.2 Gen 2, RAID 0/1/5/10

Description

Ideal Capacity For Demanding Production Workflows
Available in capacities up to 72TB, the G-RAID Shuttle 4 device delivers high performance storage to save all your favorite 4K or 8K high dynamic range (HDR) and high frame rate (HFR) footage in a single location.

Removable, Ultrastar™ Enterprise-class 7200RPM Hard Drives
For all your demanding workloads and mission-critical footage, you can depend on the power and enhanced reliability of four (4) removable Ultrastar™ enterprise-class 7200RPM hard drives inside.

Up To 1000MB/s Sustained Transfer Rates
With transfer rates up to 1000MB/s, the G-RAID Shuttle 4 device delivers the performance you need to quickly ingest content and natively edit footage to make changes in real-time.

Transportable Design
Built for easy travel between your on-site production location and to the studio for post-production, the G-RAID Shuttle 4 device delivers powerful, transportable storage to help improve your workflow efficiency, wherever you are.

Optimized Support For Multi-Stream Workflows
Built for multi-stream 4K and 8K production workflows, the G-RAID Shuttle 4 device offers the bandwidth to support multi camera editing in real time, render footage with multi-layer effects, and quickly export in an efficient workflow.

Built-in Hardware RAID
For maximum performance, the G-RAID Shuttle 4 device comes in RAID 5 out of the box and supports RAID 0, 1, and 10 to provide a versatile and flexible storage solution.

Daisy-chaining for up to 5 Additional Devices
With dual Thunderbolt 3 ports, you can conveniently daisy chain up to 5 additional devices, keeping you connected to multiple drives, 4K displays and more, through a single connection to your computer.

USB Power Delivery
With support for up to 85 watts of USB Power Delivery through the USB-C™ port, this drive can charge your compatible MacBook or MacBook Pro without having to take a separate MacBook charger out of your bag..

Specifications

Storage
Total installed storage capacity	48 TB
Installed storage drive type	HDD
Supported storage drive types	HDD
Number of storage drives supported	4
HDD speed	7200 RPM
Storage drives installed	Yes
Maximum supported storage capacity	72 TB
RAID levels	0, 1, 5, 10
Data transfer rate	40 Gbit/s
Ports & interfaces
USB connectivity	Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Thunderbolt technology	Yes
Thunderbolt ports quantity	1
Thunderbolt version	3
Technical details
Device class	Large Enterprise Business
Product colour	Black
Cable lock slot	Yes
Chassis type	Desktop
Data transfer rate	40 Gbit/s
Harmonized System (HS) code	84717020
Design
Device class	Large Enterprise Business
Product colour	Black
Cable lock slot	Yes
Chassis type	Desktop
Performance
Device class	Large Enterprise Business
Hard drive
RAID levels	0, 1, 5, 10
System requirements
Mac compatibility	Yes
Windows operating systems supported	Windows 10
Mac operating systems supported	Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur
Weight & dimensions
Width	174 mm
Depth	247.7 mm
Height	266.7 mm
Packaging content
Cables included	AC, Thunderbolt
Power cables quantity	1
Packaging data
Cables included	AC, Thunderbolt
Logistics data
Harmonized System (HS) code	84717020
