StarTech.com 1-Port Gigabit Midspan - PoE+ Injector - 802.3at and 802.3af

StarTech.comSKU: POEINJ1GW

Delivery: Fast Delivery products shipped within 2 working days from date of order.

No Customs Charges Deliveries from Ireland & EU meaning no unwanted customs charges. No hidden charges.

Price:
Sale price€124.01

Tax included Shipping calculated at checkout

Description

Deliver power and data to your Power over Ethernet device using this mountable PoE+ midspanThis Gigabit Power over Ethernet (PoE+) injector supplies power and data connectivity to a Gigabit PoE-compliant device using standard Ethernet cable, at distances of up to 100 m (330 ft.).The PoE midspan is a cost-effective alternative to upgrading your existing network switch to a PoE-capable model.Convenience and cost savingsThis versatile PoE injector lets you connect a PoE-powered device (PD) to a non-PoE network switch, so you can avoid the expense and aggravation of replacing your existing switch with a PoE-enabled model. It supplies up to 30 watts of power, so you can easily power and access a high-power PoE-compliant device, such as an IP camera or a wireless access point (WAP), using traditional copper (RJ45) Ethernet cable. The midspan injector makes it easy to extend data and power connectivity to your PoE+ device across long distances, even in a remote location where a typical power outlet isn’t available.Easy to set up in mixed environmentsYou can integrate this compact injector discreetly into a variety of environments. It features a surface-mountable housing that’s perfect for installing on walls or under a desk, but it’s also palm-sized, for use on desktop surfaces.Plus, with plug-and-play operation, you can enjoy fast and hassle-free setup without disrupting your workflow.Intelligent power allocationNot sure which class your PoE device is? The Gigabit PoE+ injector automatically detects the power requirements of your connected PoE PD, and delivers the appropriate level of power without damaging your device.The POEINJ1GW is backed by a StarTech.com 2-year warranty and free lifetime technical support.The StarTech.com Advantage,
Network
Networking standards IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Duplex system Full
Power over Ethernet (PoE) Yes
Ethernet LAN data rates 10,100,1000 Mbit/s
Ethernet interface type Gigabit Ethernet
Cable types supported Cat5
Power over Ethernet (PoE) voltage 48 V
Features
Plug and Play Yes
Maximum operating distance 100 m
Product colour Black
Networking standards IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
LED indicators Power
Ports & interfaces
DC-in jack Yes
Ethernet LAN (RJ-45) ports 2
Power
Output power 30 W
Output current 0.64 A
Power consumption (max) 36 W
Power over Ethernet (PoE) voltage 48 V
Input voltage 100 - 240 V
Input current 0.75 A
Technical details
Package width 230 mm
Package height 76 mm
Power over Ethernet (PoE) Yes
Input voltage 100 - 240 V
Input current 0.75 A
Ethernet LAN data rates 10,100,1000 Mbit/s
Ethernet interface type Gigabit Ethernet
Sustainability certificates CE, RoHS
Harmonized System (HS) code 85044095
Compliance certificates CE, RoHS
Operational conditions
Storage temperature (T-T) -20 - 85 °C
Operating temperature (T-T) 0 - 45 °C
Operating relative humidity (H-H) 10 - 90%
Weight & dimensions
Package weight 1 kg
Package depth 190 mm
Package width 230 mm
Package height 76 mm
Weight 50 g
Width 63 mm
Depth 70 mm
Height 25 mm
Packaging data
Package weight 1 kg
Package depth 190 mm
Package width 230 mm
Package height 76 mm
Packaging content
Power cord included Yes
Quick installation guide Yes
AC adapter included Yes
Indication
LED indicators Power
Logistics data
Master (outer) case width 400 mm
Master (outer) case length 490 mm
Master (outer) case height 260 mm
Products per master (outer) case 12 pc(s)
Harmonized System (HS) code 85044095
