Description
Management features | |
---|---|
Reset button | Yes |
Multicast support | Yes |
ARP inspection | Yes |
Switch type | Managed |
Web-based management | Yes |
System event log | Yes |
Quality of Service (QoS) support | Yes |
MIB support | Yes |
Switch layer | L2/L3/L4 |
Cloud-managed | Yes |
Network | |
IGMP snooping | Yes |
IGMP proxy | Yes |
Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
VLAN support | Yes |
Spanning tree protocol | Yes |
Rate limiting | Yes |
Port mirroring | Yes |
Number of VLANs | 4000 |
Flow control support | Yes |
Ethernet LAN data rates | 100,1000 Mbit/s |
Broadcast storm control | Yes |
10G support | No |
Policy-based routing | Yes |
Virtual LAN features | Port-based VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN |
Virtual LAN features | |
VLAN support | Yes |
Number of VLANs | 4000 |
Virtual LAN features | Port-based VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN |
Data transmission | |
Number of VLANs | 4000 |
Packet buffer memory | 1.5 MB |
MAC address table | 16000 entries |
Switching capacity | 20 Gbit/s |
Forwarding rate | 15 Mpps |
Performance | |
Packet buffer memory | 1.5 MB |
Mean time between failures (MTBF) | 513985 h |
Internal memory | 256 MB |
Flash memory | 32 MB |
Fanless | Yes |
Technical details | |
Product colour | Black |
Mean time between failures (MTBF) | 513985 h |
Ports & interfaces | |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Combo SFP ports quantity | 2 |
Security | |
Loop protection | Yes |
IP-MAC-Port binding | Yes |
Static port security | Yes |
SSH/SSL support | Yes |
Security algorithms | 802.1x RADIUS, SSL/TLS |
MAC address filtering | Yes |
IGMP snooping | Yes |
Access Control List (ACL) | Yes |
Queue scheduling algorithms | Strict Priority Queue (SPQ), WFQ, Weighted Round Robin (WRR) |
Password protection | Yes |
Authentication type | RADIUS, TACACS+ |
IGMP proxy | Yes |
DHCP features | DHCP client, DHCP relay, DHCP snooping |
Multicast features | |
Multicast support | Yes |
Protocols | |
Management protocols | SNMP v1, v2c, v3 |
Certificates | |
Electromagnetic compatibility | FCC Part 15 (Class A), CE EMC (Class A), BSMI ENC |
Certification | RoHS |
Memory | |
Packet buffer memory | 1.5 MB |
Internal memory | 256 MB |
Flash memory | 32 MB |
Design | |
Wall mountable | Yes |
Reset button | Yes |
Product colour | Black |
LED indicators | Yes |
Electromagnetic compatibility | FCC Part 15 (Class A), CE EMC (Class A), BSMI ENC |
Certification | RoHS |
Indication | |
LED indicators | Yes |
Power | |
Power consumption (max) | 161.8 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power source | AC |
Power over Ethernet (PoE) | |
Total Power over Ethernet (PoE) budget | 130 W |
Power over Ethernet (PoE) ports quantity | 8 |
Power over Ethernet (PoE) | Yes |
Operational conditions | |
Storage temperature (T-T) | -40 - 70 °C |
Storage relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 50 °C |
Operating relative humidity (H-H) | 10 - 90% |
Heat dissipation | 551.74 BTU/h |
Weight & dimensions | |
Width | 267 mm |
Depth | 162 mm |
Height | 44 mm |
Weight | 1.9 kg |
Packaging data | |
Cables included | AC |
Other features | |
Ethernet LAN data rates | 100,1000 Mbit/s |
Packaging content | |
Cables included | AC |
